32''55''65'' outdoor lcd sunlight readable information kiosk sensor

Product category: Wall Mounted

Features Highlight:

1. Sun readable under direct sunlight

2. Vandal-Resistant Construction

3. Easy to Service Modular Design

4. All Weather Proof IP65 Enclosures

5. 6mm AR Bonding TM-special glass

6. High-Brightness LCD Panel

7. Automatically Adjust Monitor Brightness

8. Operating Temperature -40 to 55

9. Integrated heater and air conditioner

10. Intelligent surveillance

Detail 46 inchAll Weather Outdoor LCD-OD46L02

All Weather Outdoor LCD

√ Waterproof enclosure, outdoor anti-corrosion for 7 years

√ Various custom mounting methods, such as wall mounting, floor standing, etc

√ Modular design, easy to maintain

√ AR bonding TM-protection glass, anti-glare

√ IP65 LCD

Outdoor LCD can be used in extreme environments

√ Intelligent Air conditioner integrated cooling and heating

√ Environment temperature -40--55

√ Adopt patent thermal technology

√ LCD will not turn black under direct sunlight

√ Use R134a R410a environmental friendly refrigerant

√ Monitor LCD inside running state such as temperature, humidity and vibration

Sun Readable LCD

√ High bright Panel 1500-2500cd/m2

√ LED backlight, environmental friendly and energy saving

√ Support HD picture, resolution 1920*1080

√ Temperature control system by patent technology

√ LCD keeps 7*24 hours continuours runing without bright attenuation

√ With light sensor, automatically adjust the brightness

46 inchAll Weather Outdoor LCD Specification

High Brightness Panel

Size 46 inch(1018 mm *572mm)

Aspect Ratio 16:9 landscape

Resolution 1366*768 HD

Brightness 1500 cd/m2

Contrast Ratio 3000:1

Viewing Angle 178° Horizontal / 178°Vertical

Working Parameter

Video Interface VGA HDMI CVBS S-Video

Audio interface AUDIO IN

Brightness Control automatic optical sensor systems

Working Temperature -40°C to +55°C

Working Humidity 5% to 100%

Power Source AC 108-115V./AC 208-240V

Maximum Power 1.0 Kw

Waterproof LCD Enclosure

Protection Grade IP65

Machine size (W*H*D) 642.6 mm*1088.4 mm*328.5 mm

G.W 146kg

Installation Type VESA or customized

Glass 6mm laminated with anti-reflective safety glass

Temperature control system Integrated heater and air conditioner

46 inchAll Weather Outdoor LCD Optional

1. Embeded digital signage play system

2. MINI-PC information issue system

3. Outdoor touch screen

4. Inside condition monitor system

5. Anti-graffiti protection on surface

6. Customized shape and color of enclosure

XunBao can supply 23 inch--80 inch outdoor LCD advertising player, which is integrated touch screen, WIFI, networks, info broadcasting, and remote monitor control system.

Products application: Public information, Passenger Terminal, schools and university, theme park, casino, shopping mall etc.
