Advertising show P12 outdoor led panel
- Payment Type:
- T/T
- Incoterm:
- EXW
- Min. Order:
- 1 Square Meter
- Min. Order:
- 1 Square Meter
- Delivery Time:
- 20 Days
- Transportation:
- Ocean, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Guangdong, China (Mainland) |
|---|---|
| Payment Type: | T/T |
| Incoterm: | EXW |
| Certificate: | CE,FCC |
| Transportation: | Ocean,Air |
Advertising show P12 outdoor led panel
Quick Details:
1.High performance
2.High reliability
3.Stable capability
Product Features:
1. High brightness and low light attenuation, low work voltage, low power consumption, long service life, high luminous density, wide horizontal and vertical viewing angle.
2. Excellent consistence of white balance and high contrast, uniform color and high definition & clear images.
3. Auto-adjustment of brightness according to external environment, thus no light pollution.
4. Able to remote control power switch.
5. 100% polycarbonate (PC) as the he raw material of cover/casing of module, so with no distortion, no cracking and good toughness, suitable for outdoor all-weather harsh environments.
6. Fire rating 94-V0, anti-UV(ultraviolet), high temperature resistant, weather resistant.
7. Installation by unit cabinets/ panels entire assembly enables high flatness; moreover, it is corrosion resistant, water-proof, moisture-proof, lightning-proof, and with strong overall seismic performance
maintenance way--front maintenance
Specification:
Module size
192mm(W)*192mm(H)
Pixel pitch
12 mm
pixels Density
6944 dots/sqm
Pixel configuration
1R1G1B
Brightness of single LED
R: 800mcd, G: 2400mcd, B: 600mcd
Pixel resolution
16 dots(W)*16dots(H)
Max Power consumption
40 w
Best viewing distance
12 ~ 50m
Best viewing angle
120°(H) /90°(V)
Working humidity
90 ~ 95%
Working voltage
AC220V ± 10%/ AC110V ± 10%
Average Power consumption
450 ~ 610 w/sqm
Max. Power consumption
≤ 950 w/sqm
Current
≤20mA(single LED)
CPU
Pentium 4 or above
Operating system
WIN 98/2000/NT/XP/me
control method
Synchronization, asynchronism are available
Driving device
DVI graphic card + full color controller card
MTBF
≥10,000 hours
Life span
About 100,000 hours
