Dedicated Blowing Film Corona Machine

HY-3000 corona treating machine are made of generator and discharge rack.

1.Imput Voltage:AC220V±10% 50/60HZ

2.Output Voltage:6KV-10KV

3.Output power:1kw-3kw

4.Output frenquency:15KHZ-20KHZ

5.Length: 400mm 800mm 1000mm 1200mm

Treating sides:double sides

Discharge electrode: 4fin electrode

Corona principle and role

Use high-frequency high-voltage on power pole in the discharge between the rollerand corona, low temperture plasma formed by iionization of air between the ploes to produce ozone,which is a strong oxidizer, can change the molecular structure of plastic surface to make it non-polar into polarity. at the same time after the corona treating, it will cause uneven surface hole roughen,it will enhance surface activity, such as the increase in surface tension, that is , ink,glue,etc,willbe able to further penetrate the materials and processed to achieve the idea effect on the printing and glue application.
