Cd503-508 Corona Main Frame And Oil Box

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

CD503-508Corona generator and oil box

Model	Input Voltage	output voltage	output power	out put frequency
CD-502	AC220V ±10% 50/60Hz	10KV-12KV	2KW	10KHZ-25KHZ
CD-503(split type)	AC220V ±10% 50/60Hz	10KV-12KV	3KW	10KHZ-25KHZ
CD-503(carbinet type)	AC220V ±10% 50/60Hz	10KV-12KV	3KW	10KHZ-25KHZ
CD-505	AC380V ±10% 50/60Hz	12KV-15KV	5KW	15KHZ-30KHZ
CD-506	AC380V ±10% 50/60Hz	12KV-15KV	6KW	15KHZ-30KHZ
CD-508	AC380V ±10% 50/60Hz	12KV-20KV	8KW	15KHZ-30KHZ
CD-510	AC380V ±10% 50/60Hz	12KV-20KV	10KW	15KHZ-30KHZ
CD-515	AC380V ±10% 50/60Hz	12KV-20KV	15KW	15KHZ-50KHZ
CD-520	AC380V ±10% 50/60Hz	12KV-20KV	20KW	15KHZ-50KHZ

Adopt IGBT module driver

Alarm function: start,film broken,overload,high temperature,wet start function,memorizing function ,work frequency automatic tracking

Optional

The output power is same speed as the automatic tracking Adjustment automatically

Optional:roller,Ozone extractor, Blowers tube

Discharge rack: width according to customer requirments

Corona principle and role

Use high-frequency high-voltage on power pole in the discharge between the rollerand corona, low temperture plasma formed by iionization of air between the ploes to produce ozone,which is a strong oxidizer, can change the molecular structure of plastic surface to make it non-polar into polarity. at the same time after the corona treating, it will cause uneven surface hole roughen,it will enhance surface activity, such as the increase in surface tension, that is , ink,glue,etc,willbe able to further penetrate the materials and processed to achieve the idea effect on the printing and glue application.

installation in compound machine

Currently HeFeng corona adopted the stable, advanced, reliable, imported high power IGBT module, the main components which device control, trigger, display the circuit is composed of integrated circuit block.digital display, make the equipment running very safe and reliable, durable, low failure rate, and with over-voltage overload, over current, short circuit and automatic self-protection, It is thepopualr trend of the corona at home and abroad. Due to the use of power device IGBT, the product structure is compact and the circuit connection is simple reliable, high efficiency, compact ,easy use, one button operation and modular in structure, convenient maintenance and low price.

For more details, please feel free to contact me, any inquiry from you is appreciated!
