Color Pixim Box Wdr Camera With 1/3" Seawolf Sensor

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Pixim Box WDR Camera Main Features:

● 1/3" WDR Pixim Seawolf Sensor, 690TVL;

● Min.illumination:Color 0.1Lux,B/W 0.01lux(Slow shutter);

● Super WDR:102dB typical,120dB Max;

● Superior color rendition, efficient image compression, Video rate adjustable ,PAL/NTSC optional;

● Internal/external sync, Freeze up, Electronic slow shutter, CRR, 3DNR,BLC, Mirror, Privacy zones, Motion detection(alarm image zoom in), no vertical smear in strong light;

● OSD menu, Lightingproof;

Pixim Box WDR Camera picture:

Specification:

Model	IGV-B100PIXIM
Pick-up device	1/3" WDR Pixim Seawolf Sensor
Effective pixels	758*540
Pattern	PAL/NTSC compatible(menu optional)
Pixel size	7um*7um
Sync system	Internal/External
H/V resolution	H690TVL / V460TVL
Min illumination	Color:0.1Lux(F1.2); B/W 0.01lux(Slow shutter)
S/N ratio	more than 50dB(AGC OFF)
Lens	C/CS mount lens
Electronic shutter	AUTO/OFF
WDR	High/Middle/Low/Custom
CRR	ON/OFF
BLC	ON/OFF
Exposure mode	ATM/Global/Normal/Lower1/3 /Manual
Electronic slow shutter	(64X/32X/16X/8X/4X/2X)/Off
Digital zoom	8 times
3D noise reduction	High/Low/Off
Mirror function	Horizontal/Vertical/Rotation/Off
Privacy zones	12 sets
Motion detection	4 sets
White balance	ATW/ATW PRO/PUSH LOCK/Manual
AGC	High/Middle/Low/Off
Image adjustment	Saturation/Sharpness
Image Freeze	On/Off
Other function	Lightning proof,Back focus adjustable
Day&Night	Auto/B/W/Color
Gamma	Adjustable
video rate	80-150
OSD menu	English/Chinese
Video output	1.0V p-p Composite Video Output, 75 Ohm
Power supply	DC12V+/-10%
Power consumption(Max)	200mA
Operating temp	-20°C ~ 50°C
