94v0 Pcb/pcb Prototype Chinese Maker
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Quick Details
| Place ofOrigin: | Zhejiang China (Mainland) | BrandName: | ZH | ModelNumber: | ZH-PCBA |
| Number of Layers: | 4-Layer | Base Material: | FR-4,CEM-1,CEM-3 | Copper Thickness: | 0.5-3OZ |
| Board Thickness: | 0.2-3mm | Min. Hole Size: | 0.2mm | Min. Line Width: | 0.1mm |
| Min. Line Spacing: | 0.1mm | Surface Finishing: | HALS,gold immision etc | solder mask color: | Green,black,white,red,blue,yellow |
| Inner packing: | Vaccum packing,Plastic bag | Outer packing: | standard carton paking | Hole tolerance: | PTH:0.075 NPTH:0.05 |
| PCB assembly: | high quality first | PCBA: | fast delivery |
Packaging & Delivery
| Packaging Detail: | Aluminum PCB Packages,Vaccum Packages and special packages areallowed |
| Delivery Detail: | 3-15days after your payment |
Specifications
94v0 pcb/pcb prototype
1.Reliable quality and Agileservice
2.Competitive price pcba
3.electronic pcba oem service
4.OEMODM
1.Reliable quality and Agileservice
2.Competitive price pcba
3.electronic pcba oem service
4.OEMODM
94v0 pcb/pcbprototype
Hangzhou Zhonghan Electronic Tech Co. Ltdis an aggressive and competitive manufacturer that foucusing on design,manufacture and marketing service of electronic products, and mainly deals inled products and OEM/ODM electronic manufacturing services.
Availableservice :
1.Research and manufacture electronicalproducts
2. PCB production service.
3. PCB assembly service. Available onSMT, BGA, DIP.
4. high quality led lights towards hight-endmarkets.Available on highbay light and panel light
5. Electronic Componentpurchasing service
2. PCB production service.
3. PCB assembly service. Available onSMT, BGA, DIP.
4. high quality led lights towards hight-endmarkets.Available on highbay light and panel light
5. Electronic Componentpurchasing service
One-stop pcb assembliesservice, We can offer 1 to 12 Layer PCB fabrication, PCB design, PCB layout, PCBmanufacturing, PCB Assemblies, components sourcing, PCBA Function Test, designsolution.
Turnkey PCBA Assmebly/ One-stop shopContract Manufacturing
Item |
ManufactureCapability |
|
Material |
FR-4 / Hi Tg FR-4 / Lead free Materials (RoHSCompliant) /CEM-3, Aluminium, Metal based |
|
Layer No. |
1-16 |
|
Finished Board thickness |
0.2 mm-3.8mm'(8 mil-150mil) |
|
Board Thickness Tolerance |
±10% |
|
Cooper thickness |
0.5 OZ-11OZ (18 um-385um) |
|
Copper Plating Hole |
18-40 um |
|
Impedance Control |
±10% |
|
Warp&Twist |
0.70% |
|
Peelable |
0.012"(0.3mm)-0.02'(0.5mm) |
|
Images | ||
Min Trace Width (a) |
0.1mm (4mil) |
|
Min Space Width (b) |
0.1mm (4mil) |
|
Min Annular Ring |
0.1mm (4mil) |
|
SMD Pitch (a) |
0.2 mm(8mil) |
|
BGA Pitch (b) |
0.2 mm (8mil) |
|
SolderMask | ||
Min Solder Mask Dam (a) |
0.0635 mm(2.5mil) |
|
Soldermask Clearance (b) |
0.1mm (4mil) |
|
Min SMT Pad spacing (c) |
0.1mm (4mil) |
|
Solder Mask Thickness |
0.0007"(0.018mm) |
|
Holes | ||
Min Hole size (CNC) |
0.2 mm (8mil) |
|
Min Punch Hole Size |
0.9 mm (35mil) |
|
Hole Size Tol (+/-) |
PTH:±0.075mm;NPTH: ±0.05mm |
|
Hole Position Tol |
±0.075mm |
|
Plating | ||
HASL |
2.5um |
|
Lead free HASL |
2.5um |
|
Immersion Gold |
Nickel3-7umAu:1-5u'' |
|
OSP |
0.2-0.5um |
|
Outline | ||
Panel Outline Tol (+/-) |
CNC: ±0.125mm, Punching:±0.15mm |
|
Beveling |
30°45° |
|
Gold Finger angle |
15° 30° 45°60° |
|
Lead time of prototype:
1. 10-15days, with customers completedtechnical information.
2. 12-18days, with customers samples
3. 20-25days,with customers request and our new design
Production period: 15-20days (5more days for trial order)
Advanced ProductionEquipment
Our deliverytime:
1. 10-15days, with customers completedtechnical information.
2. 12-18days, with customers samples
3. 20-25days,with customers request and our new design
Production period: 15-20days (5more days for trial order)
Advanced ProductionEquipment
Product HighQuality Perfect
Our deliverytime:
1.About Factory:
Experience: we have 20 years experinecsin circuit board manufacturing,with 50 employees and 60 excellent engineers,covering an area of 13000 square meters.Monthly capability is more than 5000square meters, 4500 types/month. we cooperate with some well-known enterprises,such as Panasonic, HP,Honeywell and so on.
2.Good after sales service:
anything wrong happening in our products willbe solved within 2 hours. we always offer relative technical support/consultant.Quick response. all your inquiry will be replied within 24 hours.
3.Ourproducts and service are sold well in North America,West Europe, Japan,Singpore, Malaysia and other countries.
Meet your need is ourgreatest pursuit .If you are looking for a pcb board manufacturerinchina,Pleasegive us your files ofpcb for a quote (Gerberfiles and specification),I will reply email in 3hours. Youalso cancontact usby .
1.Advanced production lines andprofessional staff.
2.Honesty credibility in china'stop.
3.Competest price but highquality.
4. One-stopservice.
5.Delivery ontime.
