Printed Circuit Board(pcb) Design/manufacturing electronic Pcb
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Specifications
electronic pcb:
Board thickness:1.6mm
Min.linewidth/space:10/10mil
Min.finish hole diameter:0.2mm
Finishedcopper:1oz
Board thickness:1.6mm
Min.linewidth/space:10/10mil
Min.finish hole diameter:0.2mm
Finishedcopper:1oz
electronic pcb:
Layers count:4 layers
Base material:FR4
Board thickness:1.6mm
Min.line width/space:10/10mil
Min.finish hole diameter:0.2mm
Finished copper:1oz
Surface treatment:Immersion gold
Base material:FR4
Board thickness:1.6mm
Min.line width/space:10/10mil
Min.finish hole diameter:0.2mm
Finished copper:1oz
Surface treatment:Immersion gold
| ITEM | DATA |
| plated hole dia tolerance | +-010mm/4mil |
| None plated hole dia tolerance | +-0.05mm/2mil |
| Hole position deviation | +-0.05mm/2mil |
| Outline tolerance | +-0.05mm/2mil |
| Min s/m bridge | 0.1mm/4mil |
| Twist and bent | <=1.5% |
| Insulation resistance | 10UM(Norm) |
| Through hole resistance | <300um(Norm) |
| Electric strength | >13kv/mm |
| Current strength | 10A |
| Peel strength | 1.4N/mm |
| S/M abrasion | >4H |
| Thermal stress | 288°C20sec. |
| Flammability | 90V-0 |
| Test voltage | 50-300v |
Advanced ProductionEquipment
Product HighQuality Perfect
Meet your need is ourgreatest pursuit .If you are looking for a pcb board manufacturerinchina,Pleasegive us your files ofpcb for a quote (Gerberfiles and specification),I will reply email in 3hours. Youalso cancontact usby .
1.Advanced production lines andprofessional staff.
2.Honesty credibility in china'stop.
3.Competest price but highquality.
4. One-stopservice.
5.Delivery ontime.
