94v-0 Led Pcb Circuit Board For Lg Tv Circuit Boards

94v-0 Led Pcb Circuit Board For Lg Tv Circuit Boards

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

LG TV circuit board

1.HASL/ENIG finish required to meet ROHS compliant;

2.Aluminum material within 0.2mm-3.2mm boards thickness;

3.Copper weight:0.5OZ,1OZ,2OZ,3OZ;

4.0.2mm min finished hole size;

5.Certificate: UL, ROHS, T/S16949;
6.Company management: ISO9001:2000;
7.Markets: Europe, America, Asia etc all over the world.

Technical

1).Professional surface mounting and through hole soldering technology;

2).Various sizes,like 1206,0805,0603 components SMT technology;

3).ICT(In Circuit Test),FCT(Functional Circuit Test) technology;

4).Nitrogen gas reflow soldering technology for SMT;

5).High standard SMT&Solder Assembly line;

6).High density interconnected board placement technology capacity.

Quote requirement

1).The detailed files(Gerber files,specification and BOM);

2).Clear pictures of PCBA or samples for us;

3).PCBA Test method.

PCB capacity

NO	Item	Craft Capacity
1	Layer	1-28 Layers
2	Base Material for PCB	FR4, CEM-1, TACONIC, Aluminium, High Tg Material, High Frequence ROGERS ,TEFLON, ARLON, Halogen-free Material
3	Rang of finish baords Thickness	0.21-7.0mm
4	Max size of finish board	900MM*900MM
5	Minimum Linewidth	3mil (0.075mm)
6	Minimum Line space	3mil (0.075mm)
7	Min space between pad to pad	3mil (0.075mm)
8	Minimum hole diameter	0.10 mm
9	Min bonding pad diameter	10mil
10	Max proportion of drilling hole and board thickness	1:12.5
11	Minimum linewidth of Idents	4mil
12	Min Height of Idents	25mil
13	Finishing Treatment	HASL (Tin-Lead Free), ENIG(Immersion Gold), Immersion Silver , Gold Plating (Flash Gold), OSP, etc.
14	Soldermask	Green, White, Red, Yellow, Black, Blue, transparent photosensitive soldermask, Strippable soldermask.
15	Minimun thickness of soldermask	10um
16	Color of silk-screen	White, Black, Yellow ect.
17	E-Testing	100% E-Testing (High Voltage Testing); Flying Probe Testing
18	Other test	ImpedanceTesting,Resistance Testing, Microsection etc.,
19	Date file format	GERBER FILE and DRILLING FILE, PROTEL SERIES, PADS2000 SERIES, Powerpcb SERIES, ODB++
20	Special technological requirement	Blind & Buried Vias and High Thickness copper
21	Thickness of Copper	0.5-14oz (18-490um)

PCB Superiority

1.High efficiency&Experience

We can provide one stop service.Established in 1998, with many years hard-working and constant innovation,we have

grown up into a professional PCB&PCBA manufacturer. We have our own independent research and development

department and sophisticated quality control system.

--------------------------------------------------------------------------------

2.Quality

Our product are manufactured according to the UL/Rohs standards to insure quality assemblies from start to finish. Whether

it's a simple custom or not.Product or a complex turnkey production run, We will adhere to the highest quality standards.

--------------------------------------------------------------------------------

3.Protecting your interests
Protecting your Intellectual Property is job one! Our staff of trained professionals are all working under a strict confidentiality

contract and treat your important documentation as they would their own.

--------------------------------------------------------------------------------

4.Service

We can provide 24hours service for you. We pride ourselves on our ability to custom tailor programs around our customers'

needs.We take time to listen to your unique business needs and then set out to surpass them.

PCB Quotation Need

A. PCB GERBER file and specification .

B. Your special requirementsfor the PCB Board.

C. Your testing instructions if you wanna test.

LG TV circuit board
