32ch Multi-languages Menu Standalone Dvrs

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Products :32ch Multi-languages menu standalone DVRs

Model		AP-7032C
System	Main Processor	High performance embedded microprocessor
	System Resource	Pentaplex: Live recording, Playback, Backup, Remote access, PTZ control, Mobile monitoring
	Control Mode	Front panel, USB mouse, IR remote control, Keyboard, Network
Video	Input	32CH,BNC,(1.0Vp-p,75Ω)
	Standard	NTSC 960F/S,PAL800F/S
	Output	1BNC,(1.0Vp-p,75Ω),1VGA
Audio	Input	8 ×RCA
Audio	Output	1 ×RCA
Display	Display Split	1/4/8/9/16/24/32
	Resolution	VGA:12801024, 1024768, 800*600, HDMI:1080P
	Tour Display	Support
Recording	OSD	Camera title, Time, Video loss, Motion detection, Recording
	Video/Audio-compression Standard	H.264/ADPCM
	Image Resolution	D1(720576/720480), HD1(720288/720240), CIF(352288/352240)
	Encoding Stream	Main stream: 30FPS/CH(CIF) 15FPS/CH(HD1) 7.5FPS/CH(D1)
	Encoding Stream	Extra stream: 1-5FPS/CH(CIF)
	Recording Mode	Manual, schedule(regular continuous), MD(Video detection: <Motion detection, Video blank, video loss>, Alarm)Stop
	Recording Priority	Manual>Alarm>Motion detection
	Recording Interval	5-120mins(default:60mins)
Video detection & Alarm	Trigger events	Recording, PTZ movement, Alarm, E-mail
	Motion detection	Zones:396(22*18),Sensitivity:1-5(Level 5 is the highest)
	Video loss	Support
	Alarm input/output	16CH input/1CH output
Playback & Backup	Playback channel	16ch one time
	Playback speed	CIF: 30FPS/CH HD1: 15FPS/CH D1: 7.5FPS/CH
	Search mode	Time/date, Alarm, Motion detection
	Playback function	Play, Pause, Stop, Fast forward, Slow forward, Full screen etc. Recording files can be viewed by dragging the progress bar back and forth
	Backup mode	U-disk/Hard disk/USB CD/DVD-RW/Download
Network	Physical interface	RJ-45port(10/100M)
	Network function	TCP/IP,UDP,DHCP,DNS,IP filter, PPPOE, E-mail, Alarm server, UPNP, DDNS,DNS Binding
	Remote operation	Monitor, PTZ control, Playback, System setting, files download, Log information
	Mobile monitoring	Support Window Mobile, Symbian, Android, iPhone, Blackberry etc.
Hard Disk	Hard disk	2 SATA port, the capacity of single hard disk has no limit
	Space occupation	Audio: 14.4MB/H, Video: 56-900MB/H
	HDD management	Hard disk hibernation technology, HDD faulty alarm, file restoration
Auxiliary Interface	USB	Two USB2.0 interface, for connecting mouse, U-disk, USB hard disk
Auxiliary Interface	RS485	PTZ control
Environment	Power supply	12V/6A
	Working	-10℃~+55℃/10~90%RH/86~106KPa
	Dimension	40040070mm(Product size)
	Weight	5.0 kg(W/O HDD)

32ch Multi-languages menu Standalone DVR
