4ch All In One Lcd Standalone Dvr

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Products :4ch all in one LCD standalone DVR

4CH all in one LCD standalone DVR

1. 15"LCD all-in-one StandaloneDVR

2. Adopts the standard main profileH.264compressiontechnology,

D1recording ,supports 4ch recording, Network transmission, and playback simultaneously

3. Support dual-stream transmission for all channels

4. Support Multiplex operation: live, record, playback, backup, network transmission, mobile phone surveillance

5. Support backup with USB Flash Disk, Movable hard disk, USB writer, Network

6. Support1channel. Main output, 1channel. VGA output

7. Supportvideo channelhiddenand S.E.Q for single channel

8. SupportDigitalZoom and PIPpreview

9. Support password watermark function to avoid data modification

10. Support Email alarm

11 Mobile phone surveillance (Win CE/ Symbian /iPhone/Blackberry)

12. Support PTZ preset and Cruise Control

13. Support Multi-language OSD

14. Central management software and Networked system management

15. Support mouse, remote controller, panel operating 4chALLinoneLCDstandaloneDVR

Model	AP-1504L
Operating system	Embedded Linux OS
Video Compression Format	Main Profile H.264
Video Input	4 Channels BNC
Video Output	1 Channel BNC ,1 Channel VGA(1280*1024)
Audio Input/Output	4Channel RCA Input,1 Channel RCA Output
Display Picture	1/4
Digital Zoom\PIP	Supports
Multiplex Operation	Live\display\Playback\Recording\Backup\ Mobile phone Surveillance \Network simultaneously
Display Resolution	PAL:D1(704576),NTSC:D1(704480)
Recording Mode	Manual\Timer\Motion Detection\Alarm
Recording Frame Rate	D1@50fps,HD1@100fps,CIF@200fps adjustable
Recording Resolution	PAL:D1(704576) NTSC:D1(704480)
Recording Playback	1/4channelplayback simultaneously(Optional playback channel)
Recording Backup	USB\Moved Hard Disk\USB Writer\Network
Network transmission	4Channels real-time Network transmission with QCIF resolution
Recording Play	Special player, Support AVI file format conversion
JPEG capture function	support,3M Pixels@10fps
Alarm input/output	4 channels input,1 channel output
Email Alarm	Send pieces to the designated email
PTZ	Supports PTZ preset ,Cruise Control and PC client port setup
PTZ protocol	PELCO-D,PELCO-P
HDD	Support 1 SATA HDD, capacity to 2T
HDD Remain Time Hint	Support
Network and Protocol	1 RJ-45 10/100M via Ethernet, Support TCP/IP\PPPOE\DHCP\DNS\DDNS\NTP\UPNP
IE Browser	Support
Client Software	Support
CMS	Support(One software for at most 50 DVR ),Free supply to use
Dual Stream	Support(Main and secondary interchange)
Group play	At least Support five users online access
Privacy Mask	Support
S.E.Q	Support single channel and grouping S.E.Q
Watermark	Support
Multi-language	Support
Mobile Phone Surveillance	Support Windows\ Symbian\ iPhone\Blackberry Operation System
SDK Package	Available
Mouse Interface	USB2.0
Backup interface	USB2.0
Remote Controller	Support(Supports controller ID matching)
User Authority	Support Multi-level user authority distribution
DST	Support
Power	DC12V/3A
Working Temperature	0℃-50℃
Working Humidity	10%-90%
LCD Size	15 inch 4:3 CCFL XGA
