Products : 1080P Panasonic CMOS HD camera

1080P Panasonic CMOS HD camera
1080PPanasonicCMOSHDcamera

HD-SDI CAMERA,CMOS Megapixel sensor
Support WDR,3D-DNR
DAY andNIGHT ICRfunction
OSD menu,Motion detection
Digital Zoom function
SDI andVIDEO dualsignal output
Convenient for test andinstallation
IR Led :42pcs*￠5mm,IR Range:40M
Match 2.0 Mega pixel 2.8-12mm,ICR+DC lens
1080PPanasonicCMOSHDcamera

Model	AP-W2018
Image Sensor	1/3"Panasonic CMOS
Total Pixel	2010(H)x 1108(V)
Active Pixel	1944(H)x 1092(V)
Scanning system	Progressive
Resolution	Digital:1080(30P), 720(60P) Max: 1,100TV lines(1080P)
Min.Illumination	Color: 1.0 lux, BW : 0.5 lux,
Min.Illumination	ColorDSS : 0.002 lux, BW DSS : 0.0008 lux
Video Output	Digital: BT.1120, HD-SDI, Analog : NTSC/PAL CVBS(w/oWDR)
S/N Ratio	Morethan 50dB (AGC off)
Function
Lens	4~9mm/2.8-12mmLens optionals
AGC	0– 20 steps
IRLED	42PCSIR LED, 40Meter IR distance
Shutter Speed	AUTO/MANUAL(1/50(60)~ 1/60,000 sec)
Digital Slow Shutter	Off/On(x4)
Brightness	0- 20
WDR/BLC	Off/BLC/WDR
ACE	Off/On
Day&Night	Auto/Color/B&W
White Balance	Auto/Autoext/Pushing/Manual
DNR(Digital Noise Reduction)	Off/Low/Middle/High
Mirror	Off/On
Flip	Off/On
Sharpness	0– 10 steps
Shading	Off/On
Digital Zoom	0– 96 steps
Privacy Mask	32Masks
Motion Detection	Off/On
Language	Chinese/English
Electrical
Power(Max.) supply	DC12V,Less than 1.5Watts
General
PowerInput	Connector
VideoOutput	SDI:SMA connector, CVBS: BNCconnector
