Smd Dst310 Crystal Oscillator 32.768khz

smd crystal oscillator      SMD DST310  32.768kHz

Frequency Range:  32.768kHz

Frequency Tolerance (at 25 oC):  ±20PPM

Frequency Stability Over Operating Temperature Range:  -40~+85℃

Shunt Capacitance (C0):  1.1 pF typical

Motional  Capacitance: 2.2fF typical

Insulation  Resistance: 500M ohm Min

Drive Level: 0.5 μW Max

Load Capacitance: 9.0pF,12.5pF

Peak Temperature{Frequency}  25℃ ±5℃

Frequency-Temperature Coefficent :-4 10/℃²Max

Aging (at 25 oC) : ± 3 ppm / year Max

Storage Temperature Range: - 55 ~ + 125℃


SMD DST310 crystal oscillator 32.768kHz

• IT application
• Telecommunication
• PC main board
• Data communication
• Automotive electronics
• Audio / Video

SMD DST310 crystal oscillator 32.768kHz

FEATURE
All metal welded package
Wide frequency range:32.768kHz
C-MOS IC circuit construction built-in with tristate function
5V and 3.3V supply model available
CMOS/TTL compatible in general application

How to order?

A,Get an quotation or send RFQ online by MSN, SKYPE

B,Send the quotation within 24hours

C,Place order to us

D,Confirm order and PI

E,Arrange parts

F,Ship the part and send tracking number

Payment Term

A, T/T in advance

B, Escrow

C, Western Union

D, Net Terms

How to ship?

We will arrange shipment within 1-2 working days after confirming buyer's payment.

If you don't have an account with any courier, we can help you to prepare the transport on our side and prepay the shipping cost here. We can ship our parts by DHL, UPS, FedEx, TNT and etc. to most places of the world. If youprefer any other shipping ways, please tell us and we'll check if it is available. We will ensure the lowest shipping cost.

Packaging Details






How to Track?

Your sales will provide the tracking number once our warehouse sends your parts out. Please confirm the receipt of the products if you received the Parcel, and if the goods have any damage, please contact us immediately.

More semiconductor list, welcome visit our website, contact our saleman to get a quotation.
