19v Dc Switching Power Adapters 2a Desktop , Laptop Power Charger

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Frequency Range:	47-63Hz	Voltage:	19VDC
Current:	2A	Power:	38W
Safety Approvals:	UL/cUL/GS/CE/CB/C-TICK/CCC/PSE/EMC/FCC	Compliance:	RoHS, PAHS, REACH, WEEE

90-264VAC Input voltage
47-63Hz Frequency range
19VDC Output Voltage
2A Output Current

19V DC Switching Power Adapters 2A Desktop , laptop power Adapter

Quick details:

Switching power supply,

Laptop power adapter

Desktop power AC adapter

Product Description

Switching power supply
1) High quality, High efficiency, extra safe design
2) I/P: 100-240VAC 50/60Hz, O/P: 19V 2A
3) RoHS, REACH, PAHs compliant
4) UL, GS, CE, C-TICK, PSE, FCC approved
5) Energy efficiency: CEC V, EUP 2011, MEPS V

SPECIFICATION
Input	Input voltage	90-264VAC
	Frequency range	47-63Hz
	Inrush current	50A Max, 120VAC at max load, 80A Max 240VAC at max load
	Leakage Current	0.25mA max
	Energy efficiency	CEC V, EUP 2011, MEPS V
Output	Voltage	19VDC
	Current	2A
	Power	38W
	Load regulation	+/-5%
	Hold-up time	10ms minimun at 115V AC / full load
Connector	DC cable	2468 2C 6FT or others
Connector	DC plug	Per customer request
Protections	Short circuit protection
	Over voltage protection
	Over current protection
Envionmental requirements	Operating Temperature	0-40°C
	Storage Temperature	-20-80oC
	Operating Relative humidity	10-90% RH
Others	MTBF	50K hours at 25'C
	Led indicator	Optional
	Size	1205217mm (LWH)
Safety Approvals	UL/cUL/GS/CE/CB/C-TICK/CCC/PSE/EMC/FCC
Standards	UL60950-1,IEC/EN60950-1,AS/NZS60950-1,J60950,FCC part 15 class B
Compliance	RoHS, PAHS, REACH, WEEE
