Hot sales 1200mm Dimming T8 LED Tube

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

Certification	CE, RoHS and FCC
Warranty	2 years
Power	8-21W
Life	50,000 hours
Package	Yes
Color Tones	Warm Color
Length	120cm
Illuminant	LEDs
Light Source Chip	CREE
Voltage	220V

Detail Description

We are top 20 LED Tube manufacturer in China, professional in LED Tube,T8 LED Tube , LED panel , LED Spotligh. Providing unique design super quality LED Tube lights. All our Tube lights have pass CE RoHS FCC approval.

1200mm Dimming T8 LED Tube

Specifications

Module

ESD-ZRG-T8-1200 –TDP21 (4FT)

Specifications:
Total power	8-21W
Input voltage	AC90-250V, 50/60Hz
Power supply	internal constant current
Lighting source	low power 3528/3014/5050 LEDs
LED quantity	288pcs
Dimension	Φ30mm*1198mm
Material	aluminum PCB and housing & PC cover
Luminous flux	700-1600lm±10%
Luminous efficiency	75–85lm/W
Color temperature	3000-3500K, 4500-6500 K, 6500-9000K
Viewing angle	≤120 °
CRI	Ra﹥70
Working temperature	-20～40℃（-4～104 °F）
Environment humidity	<95﹪
Working environment	indoor use
Protection rating	IP44
Life-span	50,000 hours
Weight	450g
Certification	CE, RoHS and FCC
Warranty	2 years

Features:

The 1200mm dimming T8 LED tube is powerful and big but will more functions. It is dimmable with convenient traditional switch. LED light bulbs represent the cutting edge of light bulb technology and are now available in replacement models for all uses whether at home or office.
For the people who wants go green and save money on their energy bills, but is sick of flickering, yellow compact fluorescent light bulbs that take forever to warm up, the LED light bulbs are the answer to their prayers.

Applications:

1.Low energy consumption, saves 60% power comparing conventional lights
2.No need for starter and ballasts, instant soft-start, no speckle, no flickering, no humming, no buzzing, no RF interference
3.Easy to install, replace T8/T10 conventional fluorescent light directly low maintenance cost. Lower costs by reducing re-lamp frequency, especially in difficult to reach areas that require lifts
4.Long life-span: life time 30,000hrs, 6 times longer than traditional fluorescent tubes
5.Different length available: 60cm/90cm/120cm/150cm/180cm/240cm

1200mm Dimming T8 LED Tube Dimension

Dimming T8 LED Tube Eelectric Connection Diagram

1200mm Dimming T8 LED Tube Light Installation
1 Don’t take the tube apart
2 Recommend indoor use
3 Please use it in a ventilation environment and keep it from water.
4 DO NOT connect power (positive & negative) to the two pins at one end only. If they are connected together (positive/negative), you will create a short circuit!
6 Strict quality control, lighting aging for 72 hours and complete inspection before shipping
7 Solid-state, high shock resistant, strong packaging, convenient to transportation

1200mm Dimming T8 LED Tube Test Report

1200mm Dimming T8 LED Tube Spectrum Report

1200mm Dimming T8 LED Tube Installation
