Best Price Dimming LED Tube
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| Certification | CE, RoHS and FCC |
|---|---|
| Warranty | 2 years |
| Life | 50,000 hours |
| Power | 4-14W |
| Package | Yes |
| Color Tones | Warm Color |
| Length | 60cm |
| Illuminant | LEDs |
| Light Source Chip | CREE |
| Voltage | 220V |
Detail Description
We are top 20 LED Tube manufacturer in China, professional in T5/T8/T10 LED Tube, Providing unique design super quality LED Tube lights. All our Tube lights have pass CE RoHS FCC approval.
Specifications:
| Total power | 4-14W |
| Input voltage | AC90-250V, 50/60Hz |
| Power supply | internal constant current |
| Lighting source | low power 3528/3014/5050 LEDs |
| LED quantity | 144pcs |
| Dimension | Φ30mmx590mm |
| Material | aluminum PCB and housing & PC cover |
| Luminous flux | 250-800lm±10% |
| Luminous efficiency | 75–85lm/W |
| Color temperature | 2700-4500K,4500-6000K,6000-9000K |
| Viewing angle | ≤120 ° |
| Working temperature | -20~40°C(-4~104 °F) |
| Working environment | indoor use |
| Protection rating | IP44 |
| Life-span | 50,000 hours |
| Weight | 280g |
| Certification | CE, RoHS and FCC |
| Warranty | 2 years |
Module
ESD-ZRG-T8-0600-TDP11 (2FT)
2 High quality light source. The attenuation of SMD LED light source is less than 3% by 3000hrs aging test under temperature 50 degrees Celsius, high luminous efficiency of single LED.
3 Advanced constant current driver with short circuit protection, open circuit protection, overload protection, etc.
4 Superior raw materials. Made of high quality aluminum material, which helps to the heat dissipation and turn on delicate appearance
5 Professional thermal management. Adopts aluminum substrate tightly connected with aluminum housing by insulated glue and greatly reduce the heat dissipation
Features:
1 Triac Rotary switch dimmer with step-less dimming, using high quality silicon controlled rectifier. Exquisite appearance2 High quality light source. The attenuation of SMD LED light source is less than 3% by 3000hrs aging test under temperature 50 degrees Celsius, high luminous efficiency of single LED.
3 Advanced constant current driver with short circuit protection, open circuit protection, overload protection, etc.
4 Superior raw materials. Made of high quality aluminum material, which helps to the heat dissipation and turn on delicate appearance
5 Professional thermal management. Adopts aluminum substrate tightly connected with aluminum housing by insulated glue and greatly reduce the heat dissipation
Applications:
T8 LED tube can be extensively applied to general lighting, such as mall, store, hotel, office, supermarket, commercial building, station, bus, warehouse, signage, residential, parking lot, home, restaurant , train, railway, subway station, bank, warehouse, exhibition gallery, library, closet, factory, cabinet, cupboard, kitchen, refrigeration units etc. Replace conventional fluorescent lamp or sodium lamp. Energy efficient, environmentally friendly
Dimming T8 LED Tube Dimension
Dimming T8 LED Tube Electric Connection Diagram
600mm Dimming T8 LED Tube Spectrum Test Report
600mm Dimming T8 LED Tube Installation
600mm Dimming T8 LED Tube Light Installation
1 Before installation, check whether the power is suitable. The tube must work under the right voltage according to the specification.
2 Cut off the power first for safety
3 Don’t take the tube apart
4 Recommend indoor use
5 Please use it in a ventilation environment and keep it from water.
6 DO NOT connect power (positive & negative) to the two pins at one end only. If they are connected together (positive/negative), you will create a short circuit!
1 Before installation, check whether the power is suitable. The tube must work under the right voltage according to the specification.
2 Cut off the power first for safety
3 Don’t take the tube apart
4 Recommend indoor use
5 Please use it in a ventilation environment and keep it from water.
6 DO NOT connect power (positive & negative) to the two pins at one end only. If they are connected together (positive/negative), you will create a short circuit!
