Chinese PLC,EM222 16 Outputs pulse relay controller
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Product Description
Product Description
Basic Specification
| Automation Component | plc manufacturer |
|---|---|
| programmable logic controller | Siemens PLC |
| Temperature controller | Electric controller |
| HMI | Touch Panel |
| Chinese PLC | Industrial Controller |
Detail Description
(1) Product: Chinese PLC,EM222 16 Outputs pulse relay controller.
(2) Specification Description:
| Model |
EM222 8 outputs Transistor |
EM222 8 outputs Relay |
EM222 16 outputs |
EM222 16 outputs Relay |
EM222 32 outputs |
| Product Description |
8DO,24V DC;Transistor; Optical isolation with high immunity |
8DO,24V DC/250V AC Relay; high immunity |
16DO,24V DC;Transistor; Optical isolation with high immunity |
16DO,24V DC/250V AC Relay; high immunity |
32DO,24V DC;Transistor; Optical isolation with high immunity |
| The bus current consumption | 65mA | 60mA | 110mA | 98mA | 140mA |
| Power loss | 2W | 3W | 3W | 3W | 5.2W |
| Number of digital outputs | 8 | 8 | 16 | 16 | 32 |
| Signal output type· | Transistor | Relay | Transistor | Relay | Transistor |
| Isolation | Optical coupler | Relay | Optical coupler | Relay | Optical coupler |
| Rated voltage | 24V DC | 24V DC or 250V AC | 24V DC | 24V DC or 250V AC | 24V DC |
| Permissible voltage range | 20.4~28.8V DC | 5~30V DC,20~250V AC | 20.4~28.8V DC | 5~30V DC,20~250V AC | 20.4~28.8V DC |
| Rated current | 0.75A | 2.0A | 0.75A | 2A | 0.75A |
| Lamp load | 5W | 30W DC/200W AC | 5W | 30W DC/200W AC | 5W |
| Cable Length (Shielded) | 500m | 500m | 500m | 500m | 500m |
| Cable Length (unshielded) | 150m | 150m | 150m | 150m | 150m |
| Switching frequency | / | 1Hz | / | 1Hz | / |
| Lifetime contact mechanical | / | 10,000,000 | / | 10,000,000 | / |
| Lifetime contact mechanical( rated load voltage) | / | 100,000 | / | 100,000 | / |
| Dimensions(W x H x D)(mm) | 46×80×62 | 46×80×62 | 71.2×80×62 | 71.2×80×62 | 137.5×80×62 |
| Order Number | UN 222-1BF22-0XA0 | UN 222-1HF22-0XA0 | UN 222-1BH22-0XA0 | UN 222-1HH22-0XA0 | UN 222-1BL22-0XA0 |
Here are the information for your reference:
*Price: 50%-70% of Siemens
*Minimum Order Quantity: 1 Piece
*Delivery time: 2-3 days
*Software: the same Software as Siemens(free charge)
*Payment terms: T/T & Paypal & Western Union
*Product warranty: 3 years
*Product warranty: 3 years
*Quality Assurance: CE Certification.
Additional Information
| Payment Terms | T/T, Western Union, Money Order, Paypal |
|---|---|
| Minimum Order | 1 |
| Lead Time / Delivery Time | 3 Day(s) |
| Sample Available | YES |
| Delivery Details | DHL,FedEX,TNT,UPSDoor to door services |
| FOB Port | Shenzhen |
| Loading Info | FOB |
| Packing Info | New Carton packing |
| Target Market(s) | Africa(except Middle East), Central & Southern Asia, Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Southeast Asia, Western & Southern Europe |
