EM222 8 outputs expansion module Electric controller with Relay
Your message must be between 20 to 2000 characters
Contact NowBasic Specification
| Automation Component | plc manufacturer |
|---|---|
| programmable logic controller | Siemens PLC |
| Temperature controller | Electric controller |
| HMI | Touch Panel |
| Chinese PLC | Industrial Controller |
Detail Description
(1) Product: Electric controller,EM 222 8 outputs 24V DC,250V AC Module with Relay.
(2) Specification Description:
Model |
EM222 8 outputs Transistor (Related Part No.) |
EM222 8 outputs Relay |
Product Description |
8DO,24V DC;Transistor; Optical isolation with high immunity |
8DO,24V DC/250V AC Relay; high immunity |
The bus current consumption |
65mA |
60mA |
Power loss |
2W |
3W |
Number of digital outputs |
8 |
8 |
Signal output type· |
Transistor |
Relay |
Isolation |
Optical coupler |
Relay |
Rated voltage |
24V DC |
24V DC or 250V AC |
Permissible voltage range |
20.4~28.8V DC |
5~30V DC,20~250V AC |
Rated current |
0.75A |
2.0A |
Lamp load |
5W |
30W DC/200W AC |
|
|
|
Cable Length (unshielded) |
150m |
150m |
Switching frequency |
|
1Hz |
Lifetime contact mechanical |
|
10,000,000 |
Lifetime contact mechanical( rated load voltage) |
|
100,000 |
Dimensions(W x H x D)(mm) |
46×80×62 |
46×80×62 |
Order Number |
UN 222-1BF22-0XA0 |
UN 222-1HF22-0XA0 |
*Product warranty: 3 years
