12W 12V 580mA dimming led driver power supply constant current CCC/UL
Your message must be between 20 to 2000 characters
Contact NowBasic Specification
| white color Moq | 3000 |
|---|---|
| Output Type | AC |
| Usage | Electronic product, Game Player, Laptop, Linear, Mobile Phone, Other, Power, Switching |
| Connect Type | Plug In |
| Zone Of Application | Central Asia |
Detail Description
Specifications
Clients Group: Yamaha,Sharp,Hitachi..
2 years warrant
Features
* Universal AC input/Full rang;
* Protections;Short circuit/Over load/Over voltage/Over temp;
* OCP point adjustable through output cable or internal
potential meter;
* Cooling by free air convection;
* Suitable for all kinds of LED lighting,street lighting,and
moving sign applications;
* Built-in constant current limiting circuit (C.C.+C.V.mode);
* Meet 3.5KV surge immunity level ;
* For a period of 3 Years warranty;
* Batch defective rate is three over ten thousand
Technical data
Input Voltage Range:90-264VAC
Leakage Current: 0.25mA max at 264V /50Hz
Power Efficiency:80%- 90%
Output Voltage :9-13VDC
Output Current :0.56A-0.6A
Output voltage within9-13V for load step from 20% to 80%, R/S: 0.5A/us, frequency: 100Hz duration and 8ms at 80%.
Environmental specification/EMC
Operation temp:-20-40°C(refer to output derating curve)
Storage temp:-20-85°C
Size:L*W*H=52*41*30.5mm
Safety: CCC,UL,PSE
Additional Information
| Payment Terms | T/T |
|---|---|
| Minimum Order | 500 |
| Lead Time / Delivery Time | 25 Day(s) |
| Sample Available | YES |
| Delivery Details | ex-worker ,FOB shenzhen ,FOB Hk |
| FOB Port | Shenzhen |
| Loading Info | by air , by sea, by others way |
| Packing Info | as usual, package : egg crate grid +PE bag +carton |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
