High definition waterproof p12mm LED display

High definition waterproof p12mm LED display

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

Detail Description

waterproof 12mm LED display

About Products

Owning to company strength and abundant experience, various pixel and size LED displays with premium quality would be provided at rational price. Having the best engineer and sales team, we can promise you the satisfying products and responsible service. With a factory, we have the ability to meet you specific requirements in products and delivery. Collected by the bond of our products, we want to grow up and prosper with you together.

Prominent Features:

Reliant quality
Low power-consuming
Stability
Super brightness
No flicker and distortion
Rational price
Lone life-span
Water-proof

Specific Functional Features:

Multiform source file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB etc.
Information source can be from camera, video, VCD, DVD, LD, TV and so on.
High resolution with no flicker and distortion.
Brightness, contrast, saturation can be adjusted automatically and manually.
Display source information from your PC synchronously or nonsynchronously according to your order.
Advanced correcting technology to eradicate distortion.
Easy control for video and sound signal through separate interfaces.
Various language choice, such as English, France, Germany, Greek and Russian etc.

Parameter:

Pixel pitch	12mm
Pixel density	6400point /sqm
Pixel configuration	1R1G1B SMD3528
LED wavelength	R:625 -- 630nm G:520--525nm B:465--470nm
Viewing angle	140°(H)/140°(V)
Drive chip	16 constant current
cabinet dimension	800(W)400(H)X 45(T)(0.32sqm)
cabinet resolution	64(W)X 32(H)
Module arrange	4(W)X 1(H)
cabinet structure	standard
cabinet material	Iron/aluminum
cabinet weight	10kg(Iron)/6kg(aluminum)
Cabinet cascade mode	Water proof connector
IP rate	IP30
Brightness	500-600Mcd/sqm
Color temperature	6300--9000
Power consumption	100(average)/230w/sqm(max)
best viewing distance	15-45m
Working voltage	88—132VAC/176—264VAC 47—63HZ
Display scale	Advise 4:3-16:9
Refresh rate	400--600HZ
Grey scale	4096(12bit)
Frame frequency	60HZ

Additional Information

Payment Terms	T/T, L/C
Minimum Order	10 sqm
Lead Time / Delivery Time	15 Day(s)
Sample Available	NO
Delivery Details	FOB, CFR, CIF, EXW
FOB Port	Shenzhen
Loading Info	15~30days, according to the customer\'s request
Packing Info	Aluminum /Iron with wooden case
Target Market(s)	Eastern Europe, Latin America, Middle East, North America, Southeast Asia, Western & Southern Europe
