Excellent quality HCT-400-L Full Automatic Surface Mount Assembly Machine for PCB Electronics Assembly

We are instrumental in providing to our valuable customers excellent quality Automatic Surface Mount Assembly Machine which is available with following specification:

Model#: HCT-400-L
Outline Dimensions: L*W*H 1150*1050*1400mm
Total Weight: Approx 700kg

PCB:
PCB Size Min: 50mm X50mm
Max:360mm X750mm
PCB Thickness: 0.5-3.0mm
PCB Convey Direction: From Left to right

Operation System:
Software: Windows XP
Display: LCD Monitor
Input Device: Mouse & Keyboard

Vision System:
No. of Camera: 5 Sets
Mark Point Recognition Gray scale & Multi - View Shape Recognition & Edge Detection
Positioning Way: MARK by Vision Alignment System

SMD Components: 0402 - IC<40mm (Max Height 12mm)
No. Of Placement Head: 4 Nozzles
No. of Feeders: 30 Units (8mm Feeders)
Accuracy: ±0.05mm (chip & IC)
Speed: 15200CPH (maximum)

Power Supply: Single phase, AC 220V (±10%), 50Hz
Maximum Power: 1.8 KW
Compressed Air: 0.7MPA

Clients can avail this Automatic Surface Mount Assembly Machine at industry leading prices from us.

Competitive Advantages of the product
● Optimized pick / place routing design, ensures precision end speed
● Each mounting head has its own Z - direction servo motor, which is designed for vertical motion
● Configured with variety of vacuum nozzle(8MM-32MM)
● Suit for variety of SMD LED components, and high-power LED/IC
● Using imported high precision ball screw, motor, solenoid valve, cable, etc., effectively improve the placement accuracy, stability and service life of machines
