1.5KW Full Automatic PET Bottle diameter of 50 - 96mm Unsc

1.5KW Full Automatic PET Bottle diameter of 50 - 96mm Unscrambler Equipment 1.5M3 / min

LP series bottle unscrambler is based on advanced foreign technology, according to requirements of beverage filling equipment high speed development, develop a domestic leading level bottle unscramble equipment.

Specifications:

Unscrambler

Model: LP-14

Number of working positions: 14

Capacity: 5,000BPH (5000ml)

Pressure of air supply: 0.7MPa

Air consumption: 1.5M3/ min

Applicable bottles: diameter of 50-96mm, height of 165-310mm

Power of main motor: 1.5KW

Dimension: Φ2200×2340mm (dia.×H)

Machine weight: 3200Kg

Elevator

Model: TP2

Power of motor: 0.75KW

Dimension: 5400×600×3500mm (L×W×H)

Applications:

Unscrambling and sorting PET bottles

Main characteristic

• Main motor reducer adopts torque limit institutions, to prevent failure damaged machine.
• Adopt hang bottle neck air conveyor, to prevent turnover when conveying.
• The bottle unscrambler has stuck bottles detector, if bottle stuck, it will stop automatically and alarm.
• The bottle unscrambler has no bottle detector, which used for sending work signal to the elevator, the elevator will supply bottle automatically.
• Air conveyor has photoelectric switch, which control the start-stop of bottle unscrambler.
• With maintenance door and mold changing door.
• The main electrical component (transducer, PLC, photoelectric switch, relay) use Mitsubishi, Omron, Siemens and other famous brands.
• Pneumatic circuit adopt international brand product.


Specification

• Touch screen: Thinget
• Inverter: Mitsubishi
• PLC: Mitsubishi
• Pneumatic cylinder: Airtac
• Contactor & switch: Schneider
• Photoelectrical switch: Autonics
• Motor: Tekong or Siemens
