PH12 DIP346 Outdoor Advertising LED Display with 1/4 Scan Constant Current

Quick Detail:

1. DIP346;
2. 16×16 dots per module;
3. More than 5500 nits/sq.m;
4. 2 years quality guarantee;
5. 1/4 scan constant current;
6. HUB and PCB are separated.

Detail Description:

The distance of two red LED, two green LED or two blue LED is 12mm;
There are 6,944PCS LEDs for one square meter;
For a group of LED, it is composed of 2PCS red LED, 1PC green LED and 1PC blue LED.

Specifications:

Model	PH12
LED Composition	2R1G1B
LED Encapsulation	DIP346
Resolution	6,944 dots/sq.m
LED Module Pixel	W 16 × H 16
LED Module Size	W 192 × H 192 mm
Standard Cabinet Size	W 960 × H 960 mm
Cabinet	Black color
Cabinet Material	Steel water resistance
Driving Method	1/4 scan constant current
Luminance	≥5500 nits/sq.m
Refresh Rate	≥800Hz
Out of Control Dot Rate	＜0.0001
Earth Leakage Current	＜2mA
MTBF	＞5,000 hours
LED Life Span	＞100,000 hours
Power Source	110V/60HZ and 220V/50HZ interchangeable
Humidity	10%~90%
Control Software	NovaStudio
Operation System	Win2000 / XP / Vista
