Sandwich Panel Steel Prefab House

Why OutBack (portable) House?

1. Portable and relocatable buildings are the best solution

where speed, budget, and limited or temporarily-available

space are issues. Our buildings are cost effective,

customizable.

We can make house according to the customer’s layout.

2. No other kind of building allows such a quick reaction time

as Portable house. Whether it's in the case of natural

disasters,

to accommodate temporary staff increases, or to provide

classrooms, government and medical facilities, offices and

even retail "pop-ups". Our buildings are used by a very wide

range of sectors, public and private. It provide the flexibility

of buildings as stand-alones (especially useful for events and

concerts) or configurations that extend and complement

existing

long-term facilities.

3. Using a Portable house also makes sense financially. It

allows businesses and government organizations to control

their cash flow and avoid costly building projects. It's also

useful during times of growth where the future or economic

climate is uncertain and long-term capital commitments may

be premature.

4. Portable houses are reusable, so they're very

environmentally

friendly. Individual buildings may be re-purposed by the

sameuser, or moved on to a new use over the span of their

life.Regular checks and maintenance ensures every building

is delivered in the best possible condition.

Outdoor / remote area office, working camping, laboratory,

temporary classroom or hospital …

labor accommodation or sleepouts for sale or hire …

Storage, portable bathroom or toilet, public ablution …

Dimension

mm

Length

Less than 12000

Width

2850 to 3950

Height

2400 / 2600

Loading

140 m2 per 40’HQ container

Frame

1. Material: Cold formed steel profiles in a thickness of 3 to 4mm (bottom rails)

2. Surface: Galvanized + Painting

3. Connection: By bolts

4. Floor frame: Skidding + Base beam (RHS) + C-profile Purlin

5. Roof frame: Steel truss / beam + purlin

Floor

1. Floor: multiply plywood in a thickness of 15mm; water proof, environment friendly.

2. Permitted loading: 2.50 KN/m²

3. Vinyl / PVC floor covering : 1.2mm (option item)

Wall

1. Exterior cladding: profiled galvanized sheet metal, film overlaid, 0.5 mm.

2. Interior cladding: profiled galvanized sheet metal, film overlaid, 0.5 mm.

3. Insulation: 75mm EPS (density 13 kg/m 3 )

4. Load bearing capacity: 0.6 KN/m²

5. Coefficient of thermal conductivity = 0.039W/m²K

6. R value (Thermal Resistance) = 2.5m2K/W

Roof

1. External covering:EPS sandwich panel 75mm with double sides 0.5mm galvanized

color steel sheet;

2. Permitted loading: 1.00 KN/m²

3. Roof style: one slope (flat roof) or gable slope ( 2 slope)

Window

PVC sliding window with double glass

Door

Steel security door
