Product Description

17'' industrial panel PC with ATOM N270 1.6GB
SSD 16GB, DDDR2 1G memory, Max up to 2GB (Optional)
With better design of Al cooling fin on back
Touch screen (Optional)

Introduction
IPPC-1720 is an industrial panel PC with 12.1 high brightness LCD, the latest low-power motherboard, 16G SSD. It comes with 1*LAN, 4* USB ports, 2*COM, 1*VGA, 1*audio, 1*MIC.
Smart fanless-design. It has Installation methods: Panel type, wall-mounted, VESA standard etc. And The product structure is very compact and robust with better vibration and resistance.
IPPC-1720 is a cost-effective industrial grade panel PC, can be widely used in the communication, control terminal of the electric power, manufacturing, finance, traffic monitoring etc.

CPU		Onboard Atom N270 1.6G (D525 Dual core 1.8G Optional).
Chipset		Intel 945GSE+N270
Display	17″high-brightness LCD screen
Resolution	800 × 600, 300cd/m2
Memory	DDRII 1GB, up to 2GB
HDD/SSD	HDD:160GB; SSD: 16Gb/32Gb( Optional)
Audio interface	MIC-In\Line out, built-in GM3150
Network interface	1x 100/1000Mbps Ethernet controller
I/O	4×RS23 (1 supports 485/422)
	2×USB2.0
	1xLine out
	1×VGA
	2xLAN
	1xLine out
Touch screen	Resistive touch (optional)
Power Supply	DC8-28V 5A power adapter,AC100V~265v 65HZ
Cooling	Al Cooling Fin on back of the chassis
Color	Silver/Black (Optional)
Fanless	Fanless design
Dimension	390mm(L)×320mm(W)×66mm(H)
Installation	Panel type, wall- mount, table, bracket etc
Net weight	Abt 4.2Kg
Gross Weight	Abt 5.5Kg
Operating temp	-10ºC~50ºC
Humidity	-20ºC~60ºC
