Product Description
Product Description
The TBC-3412 Smart Switch provides 2 10/100M ports, one independent extension slot supporting 1 Port 100Base-Fx fiber module which can extend the network radii to 60km. The TBC-3412 supports many smart configuration such as Port VLAN, Tag VLAN, Port Enable/Disable, MAC Address Binding. Featuring high-performance, easy to use and competitive price, the TBC-3414 is an ideal solution for work-group and smart district.
Featrures
1) Support IEEE802.3, IEEE802.3u
2) 10/100Mbps Auto-Negotiation
3) 2 10/100Mbps RJ45 ports supporting Auto MDI/MDIX
4) 1 Port 100Base-Fx fiber module
5) Support Port VLAN or IEEE802.1Q Tag VLAN
6) Support Trunk, up to 1 Trunk group
7) Support Port Priority
8) Support Port Enable/Disable
9) Support Broad storm Control
10) Desktop Steel case
11) Internal power supply
Featrures
1) Support IEEE802.3, IEEE802.3u
2) 10/100Mbps Auto-Negotiation
3) 2 10/100Mbps RJ45 ports supporting Auto MDI/MDIX
4) 1 Port 100Base-Fx fiber module
5) Support Port VLAN or IEEE802.1Q Tag VLAN
6) Support Trunk, up to 1 Trunk group
7) Support Port Priority
8) Support Port Enable/Disable
9) Support Broad storm Control
10) Desktop Steel case
11) Internal power supply
| Standard Protocol | IEEE802.3 10 Base-T standard | ||
| IEEE802.3u 10/100Base-TX/FX standard | |||
| IEEE 802.3d standard. | |||
| IEEE 802.3Q standard. | |||
| Band Width | RJ 45 Port: 10/100Mbps | Optical Port: 155Mbps | |
| Operation Mode | Full /Half duplex mode | ||
| Connectors | UTP: 2RJ-45 | Fiber connector: SC/ST/FC | |
| Operation Mode | Full /Half duplex mode | ||
| Reset port | Restart | ||
| console port | For further setting | ||
| Working mode | VLAN MODE or SWITCH MODE | ||
| LED Indicators | PWR, FLINK, LINK 1X, 2X, 3X, 4X; SPD 1X, 2X, 3X, 4X | ||
| Power Supply | Internal | AC110-250V/50Hz | |
| DC -32~-72V | |||
| Power Consumption | ≤ 5W | ||
| Environmental Parameters | Work Temperature | 0° C~50° C (32 ° F ~ 122 ° F ) | |
| Storage Temperature | -40° C~70° C (-40 ° F ~ 158 ° F ) | ||
| Humidity | 5%~90% non-condensing | ||
| TP Cable | Cat5 UTP cable (the max distance up to 100m) | ||
| Fiber Cable | 8. 3/125, 8. 7/125, 9/125, 10/125μ m(the max distance up to 20 -120km) | ||
| 50/125, 62. 5/125μ m(the max distance up to 2km or 5km) | |||
| MTBF (Hours) | > 50000 | ||
| Dimensions(mm) | Internal power supply | 223mm*124mm*36mm | |
| Gross Weight | Internal power supply | 1kg | |
| Emission/Safety | FCC Part 15 , Class A, RoHS and CE Mark | ||
