AC/DC 36V 3.5ah Lead Acid Qw360-035-S Battery Charger

AC/DC 36V 3.5ah Lead Acid Qw360-035-S Battery Charger

Get Latest Price

Payment Type:: L/C, T/T, Western Union, Paypal

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Payment Type:	L/C, T/T, Western Union, Paypal

Product Description

INPUT
01 Rating Input Voltage: 110-240VAC 50-60Hz
02 Input voltage range: 100-264VAC
OUTPUT
05 Rating output voltage: 41.4V
06 Output voltage range: 30VDC~45VDC
07 Suit with Battery type: 36V 25Ah to 33Ah VRLA
08 Charging current(stage1): 3.5± 0.2@36V
09 Charging voltage(stage2): 43.5V+-0.3V
Floating voltage(stage3): 41.3V+-0.3V
10 Cut-off current(stage2 to 3): <0.7+-0.1A
11 Typical charging time: 8hour
12 Max. Output power: 158W
PROTECTION
13. Over Current Protection
14. Over Voltage Protection
15. Short circuit protection
15. Reverse input protection
LED
Red for charging, Green for charging finished
Certificate:
CE, RoHS
