GS-Ls/P-1 LED Marine Lanterns

Get Latest Price

Payment Type:: T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Payment Type:	T/T

Product Description

GS-LS/P-1 LED Marine Lanterns

Advantages
1. 1 to 4 Nautical Miles (Tc=0.74)
2. PC material with good impact protection strength, thermal stability, high transmittance.
3. Bird spike against bird drop.
4. International-advanced cold LED with low power consumption, high brightness and service life of light source reaching 100000hours.
5. LED based on obstruction light last 15 times longer than traditional light source, incandescent light.
6. About 96 less power than 116W incandescent light.
7. Major Maintenance Cost Saving, Surge protection device inside light.
8. Strong corrosion resistance, Shock and Vibrations protection and UV protection.
9. Dawn to Dusk operating: Built-in photocell can let light work automatically at night, closed during the day.
10. 3/4inches installation size and small volume especially being suitable for telecom and flag-pole installation way.
11. IP67 protection standard, Full sealing structure.

Function
GS-LS/P-1 LED Marine Lanterns is single light with Photocell. It can work at night automatically when ambient brightness is lower than 500cd/m2 and close during the day. Volume of this light is very small, so it is especially suitable for flag-pole installation way.

Scope of Application
GS-LS/P-1 LED Marine Lanterns is commonly used on both fixed and floating structures for Aids to Navigation.

Main Parameter
1. Mode: GS-LS/P-1
2. Standard: IALA
3. Light intensity: 1cd(1nm),5cd(2nm),15cd(3nm),38cd(4nm)
4. Flash rate: Flash mode or Steady-burning mode
5. Light source: LED
6. Service life of LED: 100, 000hours
7. Operating voltage: DC12V
8. Power Consumption: 1W
9. Overall Size(mm): 136 by 136 by 220
10. Installation Size: 3/4inches
11. Weight: 1Kg
12. Emitting Color: Yellow, Green, White and Red
13. Ambient Temperature: -55degree centigrade to +70degree centigrade
14. Wind load: 80m/s
15. Protection Standard: IP67

Dimension Drawing

Product Pictures

Product Profile
1. Model:GS-LS/P-1
2. Applications: Applied to both fixed and floating structures.
3. Standard: IALA
4. Improve Records: None
5. Fault Records: None
6. Quantity/Delivery Day: 20 pcs / 5 Days
