High Quality and Low Price Combo Reader (ZDM65U)

High Quality and Low Price Combo Reader (ZDM65U)
1. Product Review:

Welcome to use this new and Creative ZDM65U Reader. ZDM65U is a combo of Bar-code and RFID Scanning equipment, which owns Powerful 624MHz Microprocessor, fast Sensor Shutter and fast pulse illumination. Its functions include collect One-dimensional bar codes and Two-dimensional bar codes, fast decoding function and support most of HF cards with Frequency 13.56MHz and these will do much help to improve your work efficiency.

2. Functions
Power: DC5V/500mA(USB interface)
Light Source: Aim VLD: 655655± 10nm Laser; LED: 625± 5nm
Resolution: 752*480 pixel
Print Contrast: Minimum 25% Absolute dark/light reflectance
Horizon: Horizontal Direction: 40° , Vertical Direction: 25° ; Swing Tolerance (left and right): ± 60° ; Swing Tolerance(Front and Back): ± 60° ; Rotation Tolerance: 360°
Minimum Width: 3mil Code39; 4mil PDF417 ( High Density); 5mil Code 39; 5mil PDF417(Optimized version of driver's license); 5mil Code 39; 6.7mil PDF417(Standard Version)
Operation Distance: 1.6"/41mm~3.8"/97mm(High Density);
1.4"/36mm~7.3"/185mm(Optimized version of driver's license); . 1"/53mm/7.5"/191mm
Codes Available: One-dimensional bar codes: All of main codes; Two-dimensional bar codes: PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode
Postal Codes: US PostNet, US Plane, UK post, AU Post, JP Post, NL Post(KIX)
RFID Operating Frequency: 13.56MHz
Reading Distance: 0~50mm( It all depends on cards)
Optional Protocol Type: ISO/IEC 14443 A, ISO/IEC 14443 B; ISO/IEC 15693

3. Basic Operations
Please insert the product into the USB interface of PC, when boot music begin, no driver program will be installed by PC machine automatically, when finished, can be put into use.
Press trigger button, when display lamp turn red and Crosshair in the right location, it begin work.
Press the button for 5 seconds, when hear the"drop"tone, it will switch to RFID Mode, then press the button again, the display lamp turn blue, put the window close to the RFID Card, the the UID could appear.
If need swith to Bar code Reading Mode again, just need press the button 5 seconds.

4. Product Application
Warehouse, Logistics, Customs, Supermarket, Business Community, Telecommunication, Post Service, Tax, Bank, Insurance, Medical Care and other Two-dimensional bar codes application manage systems

5. After Sale Service
When there's something wrong with products, please contact the local maintenance point(department) at first time or contact our company sales department directly. Avoid bringing unnecessary loss, pls don't disassembly!
Guarantee of Refund within 7 days: If any problem referred to function happened within 7 days from the date of purchase, Consumers could choose refund, replacement or repair.
Guarantee of Replacement within 15 days: If any problem referred to function happened within 15 days from date of purchase, Consumers could choose replacement or repair.
Guarantee of Maintenance within 1 year: If any problem referred to function happened within 1 year from date of purchase, Consumers could choose repair for free.
