Product Description

Vertical surface mounted fan coil, air conditioner

Ideal for installation in motels, apartments, and other multi-room buildings, 42 series fan coils combine heating and cooling performance with easy, low-cost installation. The units are designed for medium static, ducted applications, using furred-in, horizontal and vertical models, or exposed ceiling painted cabinet models. Optional decorative colors allow the unit to blend with any interior design.

Beautiful appearance to fit the decoration works
Nice grille is provided at the outlet and the angle can be adjusted
Special design of the air filter, the filter can be dismantled withoutspecial tools

1, High wall fan coil unit, wall mounted fan coil unit, split fan coil
2, vertical exposed and concealed fan coil unit
3, ceilling fan coil, Floor standing fan coil
4, cassette fan coil
Can be applied for air conditioner, chillers.

Specifications
Vertical exposed fan coil unit:
With CE certificated
Coling capacity: 1.8KW to 112.6KW;
Heating capacity: 2.7KW to 19KW;
Jinhuali is a professional factory which specialized in refrigeration euquipment, such as fan coil units, water chiller and heat pump, air conditioner

Vertical exposed fan coil unit
1) Structure of series product: Units have been designed for both vertical and horizontal positioning
2) Air volume: 34, 51, 68, 102, 125 and 150
3) Electric source: 230V, 1PH, 50/60Hz
3) Structure for switch: Manual, electrical and three-speed switch
5) Hydraulic terminals are supplied accompanied by plastic envelope fixed to the top of hydraulic terminal containing
6) Instruction manual
7) Guarantee certificate
8) Can be use remote handset and wired wall pad control

Maintenance Features
Cleanable or throwaway filters (factory-installed option).
Removable panels make access to components and connections easy.
Label information adhered to each unit includes model, size, coil information, electrical information, and tagging data.

Vertical Expose Fan Coil
Model			HLC-34VE	HLC-51VE	HLC-68VE	HLC-85VE	HLC-102VE	HLC-136VE	HLC-170VE	HLC-204VE	HLC-238VE
Air flow(m 3 /h)		High speed	340	510	680	850	1020	1360	1700	2040	2380
		Medium speed	255	383	510	638	765	1020	1275	1530	1785
		Low speed	170	255	340	425	510	680	850	1020	1190
cooling capacity	High	W	1800	2700	3600	4500	5400	7200	9000	10800	12600
	High	BTU	6143	9215	12287	15359	18430	24574	30717	36860	43004
	Medium	W	1620	2440	3290	4120	4850	6550	8190	9730	11580
	Medium	BTU	5529	8328	11229	14062	16553	22355	27952	33208	39523
	Low	W	1310	2010	2650	3320	3900	5300	6610	7860	9350
	Low	BTU	4471	6860	9044	11331	13311	18089	22560	26826	31912
heating capacity	High	W	2700	4050	5400	6750	8100	10800	13500	16200	18900
	High	BTU	9215	13823	18430	23038	27645	36860	46076	55291	64506
	Medium	W	2350	3520	4530	6040	6850	9260	11740	14140	16360
	Medium	BTU	8021	12014	15461	20615	23379	31604	40069	48260	55837
	Low	W	1620	2470	3130	4170	4740	6500	8180	9710	11290
	Low	BTU	5529	8430	10683	14232	16178	22185	27918	33140	38533
Cooling water temperature			7 to 12 degree
Hot water temperature			40 to 60 degree
			AC220V/50Hz
Heat Exchanger	Type		copper pipes covered into aluminum fins, fin pitch 2.2mm
	Water supply kg/h		324	482	655	814	936	1278	1602	1915	2178
	Water resistance kPa		30	30	30	30	40	40	40	40	50
	Working pressure		1.6MPa
Low static pressure FCU		Input power w	37	52	62	76	96	134	152	189	228
Low static pressure FCU		Motor power w	10	16	20	25	30	20×2	25×2	30×2	40×2
High static pressure FCU	Static pressrue 30Pa	Input power w	44	59	72	87	108	156	174	212	253
	Static pressrue 30Pa	Motor power w	12	20	25	30	40	25×2	30×2	40×2	50×2
	Static pressure 50Pa	Input power w	49	66	84	100	118	174	210	250	300
	Static pressure 50Pa	Motor power w	16	25	30	40	50	30×2	40×2	50×2	60×2
Fan motor quantity			1	2	2	2	2	3	4	4	4
Noise dB(A)	Low static pressure		≤37	≤39	≤41	≤43	≤45	≤46	≤48	≤50	≤52
	High static pressure 30Pa		≤40	≤42	≤44	≤46	≤47	≤48	≤50	≤52	≤54
	High static pressure 50Pa		≤42	≤44	≤46	≤47	≤49	≤50	≤52	≤54	≤56
Pipe	Inlet/outlet water pipe		ZG3/4 "internal thread
Pipe	Condensation water pipe		ZG3/4" external thread
Dimension		L mm	1000	1000	1200	1300	1400	1600	1900	2100	2100
		W mm	270	270	270	270	270	270	270	270	270
		H mm	645	645	645	645	645	645	645	645	645
20GP container loading quantity			189	189	158	146	135	118	100	90	90
40GP container loading quantity			373	373	311	287	267	233	196	178	178
