Single Door Access Controller (CHD5051MK)

Parameter

CHD8028BK Access controller with EM card reader
Dimension: L128 mm× W84 mm× H28mm
Weight: 130g ( including metal hanging board )
Color: White, Black
Display: Blue backlight; Red alarm light

Power supply: DC12 (rating voltage), >200mA;
Standby current, < 40mA; Current when card reading, < 60mA
Working temperature: -10 ~ +50° C
Storage temperature: -40 ~ +50° C
Relative humidity: 90%RH

ESD Immunity Level: Air discharge ≤ ± 9KV; Contact discharge ≤ ± 6KV
Users card: 2368 pieces
With internal EM card reader, RF frequency: 125KHz
Reader distance: >8cm (depend on card quality)
Inductive speed: ≤ 1 second

OC alarm: 1 set
Tamper alert: Y
Mini appearance, powerful function, with keypad and card reader for access control operation.
Suitable for home, office and other access control application.
