Digital Coating Thickness Meter 0-1000um/0-40mil + F & Fn Probes
- Payment Type:
- T/T
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
Place of Origin: | China |
---|---|
Payment Type: | T/T |
Product Description
Product Description
Features:
* It meets the standards of both ISO2178 and ISO2316. Suitable for the laboratory and for use in harsh field conditions.
* The F probes measure the thickness of non-magnetic materials such as paint, plastic porcelain enamel, copper, zinc, aluminum, chrome etc. On magnetic materials such as iron, nickel and etc. It is often used to measure the thickness of galvanizing layer, lacquer layer, porcelain enamel layer, phosphide layer, copper tile, aluminum tile, some alloy tile and paper etc.
* The NF probes measure the thickness of non-magnetic coatings on non-magnetic metals. It is used on anodizing, varnish, paint, enamel, plastic coatings, powder applied to aluminum, brass and non-magnetic stainless steel etc.
* Used the exclusive Micro-computer LSI circuit and crystal time base to offer high accuracy measurement & fast measuring time.
* Wide measuring range and high resolution.
* Digital display gives exact reading with no guessing errors.
* The use of durable, long lasting components, including a strong and light weight ABS plastic housing assures maintenance free.
* Shaped to fit comfortably for right or left-handed person
Specifications:
* Measuring range: 0-1000um/0-40mil
* Operating Principle: Magnetic induction/eddy current (F/NF)
* Resolution: 0.1 um(0-99.9um), 1um (over 100um)
* Accuracy: ± 1-3%n or 2.5 um (Whichever is the greater)
* Battery indicator: Low battery indicator
* With Metric/Imperial readings, mils and microns
* Automatic or Manual shut down (power off)
* Display: 4 digits, 10mm LCD
* Power supply: 4 X 1.5V AA(UM-3)battery (not included)
* Operating conditions: 0-50° C Temperature, <80%RH Humidity
* Dimensions: 161mm X 69mm X 32mm (6.3" X 2.7" X 1.3")
* Weight: Approx. 260g (including batteries)
* It meets the standards of both ISO2178 and ISO2316. Suitable for the laboratory and for use in harsh field conditions.
* The F probes measure the thickness of non-magnetic materials such as paint, plastic porcelain enamel, copper, zinc, aluminum, chrome etc. On magnetic materials such as iron, nickel and etc. It is often used to measure the thickness of galvanizing layer, lacquer layer, porcelain enamel layer, phosphide layer, copper tile, aluminum tile, some alloy tile and paper etc.
* The NF probes measure the thickness of non-magnetic coatings on non-magnetic metals. It is used on anodizing, varnish, paint, enamel, plastic coatings, powder applied to aluminum, brass and non-magnetic stainless steel etc.
* Used the exclusive Micro-computer LSI circuit and crystal time base to offer high accuracy measurement & fast measuring time.
* Wide measuring range and high resolution.
* Digital display gives exact reading with no guessing errors.
* The use of durable, long lasting components, including a strong and light weight ABS plastic housing assures maintenance free.
* Shaped to fit comfortably for right or left-handed person
Specifications:
* Measuring range: 0-1000um/0-40mil
* Operating Principle: Magnetic induction/eddy current (F/NF)
* Resolution: 0.1 um(0-99.9um), 1um (over 100um)
* Accuracy: ± 1-3%n or 2.5 um (Whichever is the greater)
* Battery indicator: Low battery indicator
* With Metric/Imperial readings, mils and microns
* Automatic or Manual shut down (power off)
* Display: 4 digits, 10mm LCD
* Power supply: 4 X 1.5V AA(UM-3)battery (not included)
* Operating conditions: 0-50° C Temperature, <80%RH Humidity
* Dimensions: 161mm X 69mm X 32mm (6.3" X 2.7" X 1.3")
* Weight: Approx. 260g (including batteries)
