RoHS Certificate! Wireless PSTN Phone Dialer Alarm System with Free Door Sensors

Rohs certificate! Wireless pstn phone dialer alarm system with free door sensors

Basic functions:

1. Dual-band GSM network module.

2. Timing arm/ disarm.



3. Auto-dial to 3 user phone numbers and monitor the spot when alarming.

4. Send SMS to 3 user phone automatically when alarming.

5.10 wireless zones (1 wireless SOS zone, 1 fire alarm zone, and other 8 wireless zones can be set by user ) and 1 external power failure alarm zone.

6. Remote control to arm/disarm by remote controller or SMS commands.

7. Program the alarm system by keyboard or SMS commands.

8. Modify the name of 8 wireless zones and inquire the status of the system.

9. Set the 8 wireless zones as arm/partial arm by keyboard.

10. Color LCD show screen and keyboard.

11. Built-in rechargeable battery.

12. The host can store the system's status, when its power is off.

13. Connect with the alarm center via GSM network.

Technical parameters:

GSM frequency: 900/1800MHz or 850/1900MHz

Consumption: 1W (while sending message)

Working frequency of detectors: 315/433/868 MHz

External power failure alarm

Start-time: Less than 2s

Alarm response time: Less than 8s (GSM in normality)

Power supply: AC 110-220V 50Hz or 60Hz

Working power consumption: Less than 3W

Standby battery: DC 8.4V

Standby battery working hours: More than 15 hours

Operating temperature: -20 ~ 60º C

Humidity: 20% to 95%

Dimensions: 160 (L) x 113 (W) x 38(H) mm
