Bigpond 3G Router

*Combines Next G Broadband service, Wi-Fi and Ethernet gateway one device
*International coverage through tri-band HSUPA /HSDPA/UMTS(850/1900/2100MHz),
Quad-band EDGE/GSM(850/900/1800/1900MHz)
*Embedded multimode HSUPA/HSDPA/UMTS/EDGE/GPRS/GSM module
*CLI command interface
*UPnP
*Web-based management
*WEP/WPA/WPA2 and 802.1x
*Support VPN Pass-through
* MAC address and IP flitering
*Intergrated 802.22g AP (backward compatible with 802.11b)
*Static route fuctions
*DHCP Server/Relay/Client
*DNS Proxy
*Configuration backup and restoration
*NAT/PAT

Technical Specifications:
LAN Inteface
*Ethernet× 4
WLAN
*MAC Address Filtering, WEP, WPA, IEEE 802.1×
*10, 25, 50, 100Mw@22MHzz channel
Bandwidth Output power level can be selected according to the environment
Standard:
*IEEE802.11g, backward compatible with 802.11b
Encryption:
*64, 128-bit Wired Equivalent Privacy(WEP, WPA2)Data Encryption
Channels:
*11 Channels (US, Canada)
*13 Channels (Europe, Austrialia)
*14 Channels (Japan)
WLAN Data Rate
*Up to 54Mbps

WAN CONNECTION
PPP
*yes
Standard
*Complay with the 3GPP release 5 UMTS specification
Band
*Support Quad-band GSM/GPRS(850/900/1800/1900MHz)
*Support tri-band UMTS/HSDPA/HSUPA(850/1900/2100MHz)
Data Rate
*HSUPA(up to 2.0 Mbps uplink)
*HSDPA and UMTS (up to 7.2Mbps downlink and 384Kbps uplink)
*EDGE/GPRS/GSM(up to 247Kbps)
Antenna Type
*Removable antenna
Bigpond 3G Router MANAGEMENT
*SNMP, SNTP, Telnet, Web-based management, Configuration backup and restoration
*Fireware upgrade via HTTP, TFTP client and server, or FTP server
ROUTING FUNCTIONS
*Static route, NAT/PAT, DMZ, DHCP Client/Sever/Relay, DNS Proxy, DDNS
SECURITY FUNCTIONS
*Stateful Packet Inspection, Packet filtering, Denial of Service protection, Management
Authentication protocols
*PAP, CHAP
VPN
*PPTP/L2TP/IpSec pass-through
LED
*Power, LAN 4, LAN 3, LAN 2, LAN 1, Wi-Fi, Internet, 3G, 2G, Signal Strength for Low,
Med and High LEDs
POWER
*External power adapter
*100-240Vac to 12Vdc/1.5A
ENVIRONMENTAL CONDITIONS
Operating temperature
*0-50 degrees Celsius
Relative humidity
*5-90%(non-condensing)
DIMENSIONS
*205mm(W) × 47mm(H)× 145mm(D)

Bigpond 3G Router Technical Specifications

WAN Interface
*SIM card slot*1

LAN Inteface
*Ethernet× 4

WLAN
*MAC Address Filtering, WEP, WPA, IEEE 802.1×
*10, 25, 50, 100Mw@22MHzz channel
Bandwidth Output power level can be selected according to the environment
Standard:
*IEEE802.11g, backward compatible with 802.11b
Encryption:
*64, 128-bit Wired Equivalent Privacy(WEP, WPA2)Data Encryption
Channels:
*11 Channels (US, Canada)
*13 Channels (Europe, Austrialia)
*14 Channels (Japan)
WLAN Data Rate
*Up to 54Mbps

Bigpond 3G Router WAN CONNECTION
PPP
*yes
Standard
*Complay with the 3GPP release 5 UMTS specification
Band
*Support Quad-band GSM/GPRS(850/900/1800/1900MHz)
*Support tri-band UMTS/HSDPA/HSUPA(850/1900/2100MHz)
Data Rate
*HSUPA(up to 2.0 Mbps uplink)
*HSDPA and UMTS (up to 7.2Mbps downlink and 384Kbps uplink)
*EDGE/GPRS/GSM(up to 247Kbps)
Antenna Type
*Removable antenna

Bigpond 3G Router MANAGEMENT
*SNMP, SNTP, Telnet, Web-based management, Configuration backup and restoration
*Fireware upgrade via HTTP, TFTP client and server, or FTP server

*External power adapter
*100-240Vac to 12Vdc/1.5A

Bigpond 3G Router ENVIRONMENTAL CONDITIONS

Bigpond 3G Router DIMENSIONS
*205mm(W) × 47mm(H)× 145mm(D)
