ID Scanner and Passport Scanner for Security Solution (ACM-901)

Feature:
Reading by "Snapshot+OCR(optical character reorganization )"
Optical resolution: 300dpi
Interface: USB2.0
Image range: MAX: 126mm*95mm
Bundled Software: Software for passport and SDK
Read speed: Within two second.
Can read Passports, driver's licenses, ID cards, insurance cards and other documents
Application:

Telecom business hall window application: "Standing in Line Picking up Certificate and Drawing Number System"
Financial sector window application
Net bar real-name system management and the management system of limiting minors' surfing the internet
Restaurant front desk registration system and public security hotel information management system front desk registration application
Safety & prevention and gateman registration system
Public security sector floating population management application

Specification:
NOItemsSpecification:
1Imaging range: MAX: 126mm*95mm
2Imaging mode: Color / 8bit gray
3Image sensor: CMOS SENSOR
4Image resolution: 300dpi
5Information collection time: Lass than 2S
6Boot start-up time: Less than 2 S
7Communication Interface: USB2.0
8Imaging depth of field: 5mm
9Power supplyPower adaptor: (Input: 100-240VAC, 50/60Hz,
Output: 5VDC, 1500mA)
10Noise: Work without the noise
11Dimensions: (L, W, H): 220mm× 195mm× 96mm) (± 2%)
12Stability: 100 million times
13Software Compatibility: Support Win2000, Win XP, Win2003

Packing:

Gift box size: 361mm*346mm*215mm
Carton: 616mm*388mm*368mm
4PCS/Carton
