AC to DC Rectifier 7000W
- Payment Type:
- L/C, T/T, Western Union
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Shenzhen |
|---|---|
| Payment Type: | L/C, T/T, Western Union |
Product Description
Product Description
220/110VDC RECTIFIER MODUL
PRODUCT DESCRIPTION
Power supply modules of series SET- 220V/110V are compact battery charging rectifiers with rear side connectivity.
The rectifiers are designed for high voltage Power Plants and Substations.
Due to the modular concept and a high scalability the user is able to equip the power supply with
additional modules according to his actual power profile. The chargers are very user friendly and
can be swapped as well as upgraded during system operation.
The devices get their operation parameters via the system RS 485 communication bus.
After a successful login a central monitoring unit controls and monitors the devices. In case of interruption
due to failure of monitoring unit the modules operate continuously with internal default values.
Therefore the supply of the connected loads and the charging of the batteries are guaranteed without any interruption.
Step less temperature control fan speed & change with the output power of module, which minimize
noise & extend fan life.The rectifier needs a 1Ph AC mains connection.
Rectifier power circuit is divided into active PFC & DC to DC converter which can make the wide
input voltage range (85V-290V) & high efficiency.High power density has reached the international
advanced level.
Power supply modules of series SET- 220V/110V are compact battery charging rectifiers with rear side connectivity.
The rectifiers are designed for high voltage Power Plants and Substations.
Due to the modular concept and a high scalability the user is able to equip the power supply with
additional modules according to his actual power profile. The chargers are very user friendly and
can be swapped as well as upgraded during system operation.
The devices get their operation parameters via the system RS 485 communication bus.
After a successful login a central monitoring unit controls and monitors the devices. In case of interruption
due to failure of monitoring unit the modules operate continuously with internal default values.
Therefore the supply of the connected loads and the charging of the batteries are guaranteed without any interruption.
Step less temperature control fan speed & change with the output power of module, which minimize
noise & extend fan life.The rectifier needs a 1Ph AC mains connection.
Rectifier power circuit is divided into active PFC & DC to DC converter which can make the wide
input voltage range (85V-290V) & high efficiency.High power density has reached the international
advanced level.
FEATURESProtection for Input and output over /under voltage, over temperature, and short circuit
"Hot plug-in" design with back plane connection
High power density
RS 485 Interface for Remote Adjusting,Controlling, Measuring and Signaling.
High Efficiency with low EMI
CE Safety and EMC certification
LED indication for On / Fault status.
APPLICATIONS
These power supplies are designed for a wide range of applications such as:
Power supply for all medium to high power DC loads
Rectifiers in DC systems with battery backup
Telecommunication.
Industrial control systems.
Charging and buffering of stationary batteries in electrical power plants
This is 2U ---19'' rack systems. The whole system consists of 1 monitor+3 modules.
The monitor can display modules information, and also can set data.
