Basic Info

Product Description

Basic Info.

Model NO.

Mech

Specification

SGS

Trademark

ALLTECH

Origin

Shenzhen

Production Capacity

10, 000 PCS/Year.

Product Description

Technical Parameters
(1) Working frequency: 320~350MHz;
(2) Channel bandwidth: 2.5/3/3.5/5/6MHz;
(3) Transmission mode: TDD/TDMA full-duplex structure;
(4) Transmission system: OFDM system with LDPC encoding;
(5) Core technology: TDD, OFDM, LDPC high-efficiency error correcting; flexible subcarrier allocation and low Papr technologies;
(6) RF power output: 2W as default (adjustable);
(7) RF output interface: N;
(8) Encryption: DES encryption to avoid illegal receiving and dual security;
(9) Video quality: D1/HalfD1/CIF optional;
(10) Network data interface: RJ45;
(11) Control interface: RJ45 and RS232.
System Application
Wireless network organization among multiple communication vans in city
Networking among vans, that is, networking among mobile radio stations, has two modes: when communication vans get close to each, for instance, in a motorcade, the van always connected to its adjacent van and realizes wireless network communication among all nodes by skipped connection; if the van gets far from each, at different corners of the city, such as the important sports game safeguard activity requires so many security staffs for multiple venues, in such case the communication among vans rely on base station roaming service.
