IEC Ball Pressure Testing Machine
  • IEC Ball Pressure Testing Machine
IEC Ball Pressure Testing Machine

IEC Ball Pressure Testing Machine

Payment Type:
L/C, T/T, Money Gram, Western Union
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: Shenzhen, China
Payment Type: L/C, T/T, Money Gram, Western Union
Product Description
Product Description

IEC60695-10-2 / IEC60884-1 /IEC60320-1 Ball Pressure Apparatus

Application:


Ball pressure tester is used for testing parts of non-metallic materials for resistance to heat. It is applicable to electro technical equipment, its subassemblies and components, and to solid electrical insulating materials except ceramics.
In this test, a conditioned specimen is placed on a preheated support and subjected to a force of 20n applied through a 5 mm steel ball. The test stand, specimen and loading device are then kept in an oven at an elevated temperature for an hour. After the hour, the loading device is removed from the sample, the sample is cooled and any indentation is measured. It is important to assure that the test stand has reached a stale elevated temperature as required by the test. For this reason, the SFT ball pressure tester comes equipped with a thermocouple that inserts into the test stand so its temperature can be monitored.

Basic introduction:

Ball Pressure Apparatus/Tester is the requirement ball (R2.5mm) and total test force 20N ± 0.2N ball pressure testing device, pressure level of the state and was placed in the heating chamber on the surface of the test.
In the test temperature specified by the after 60min +2 min/0min, the test quickly (<10s) immersed in 20 ° C ± 5 ° C water cooling 6min ± 2min, 3min removed from the water surface within the indentation diameter measurement test, as the indentation is more than 2mm in diameter to evaluate the test specified in the heat deformation temperature.

Advantages:

1. 1 year warranty
2. ISO17025 is free offered
3. ILAC and CNAS can be offered if required
4. For machines , we can offer video for customer reference



IEC Ball Pressure Testing Machine
IEC Ball Pressure Testing Machine
IEC Ball Pressure Testing Machine
