27.12MHZ / 15KVA Automatic feeding High frequency plastic box folding / making Machine
Mainly Application:
Applied for PVC, APET, PETG, GAG, PP etc. materials soft crease box making under continuous operation in application of high frequency welding and folding.
High frequency plastic box folding machineFeatures:
Embossing and welding with PVC, EVA, PU, PE, TGA, PET, GAG, PP materials,
Automatic feeding material, adjustable operating speed,
Electronic counting, continuous automatic feeding speed, suitable for different materials, optional with expending set,
Imported abrasion proof transformation, avoid damaging the mould,
Photo-electricity induction, feeding-collection simultaneously, precise-controlled.
High frequency plastic box folding machine Specifications:
|
Model |
KBG-8000 P |
|
Power Voltage |
3φ380VAC 50HZ |
|
Input Power |
15KVA |
|
H.F Output Power |
8KW |
|
H.F Frequency |
27.12MHZ |
|
Rectifier |
SILICON DOIDE 2CL |
|
Oscillation tube |
7T69RB |
|
Electrode gap |
150mm |
|
Operation |
Pneumatic / Hydraulic |
|
Max. pressure |
20T |
|
Dimensions |
1433×5416×1700 mm (L×W×H) |
|
Upper mould plat |
560mm×560mm |
|
Down mould plat |
650mm×650mm |
