XL-ETFE M27500 Cable

Extruded Crosslinked Modified ETFE

2X18 AWG Unshielded XL-ETFE M27500 Cable
Applications: Multiple/Rapid deployment
General Construction:
2 XL-ETFE insulated twisted wires per MIL-W-22759/32, jacketed with a XL-ETFE, with excelent abrassion and chemical resistance for Aerocpace and Military use.
Outer Jacket Material: Cross-linked ETFE
Outer Diameter: 3.5 mm nom.
Conductor Material: Tinned Copper
Conductor Size: 18 AWG
Conductor Construction: 19x0.25 mm
Insulation Material: XL ETFE -65°C to 150°C
Insulation O.D.: 1.52 mm nom.
Conductor Color Code: White, White/Blue
Total number of wires: 2
Outer Jacket Thickness: 0.2 mm nom.
Outer Jacket Color:White
Standards
Standards:RoHS 2002/95/EC
Flamability Rating:IEC 60332-3 , IEEE 383
Performance
Max. DC Resistance : 20.4 Ω/km@20°C
Dielectric Strength: 1500 V/minute
Voltage Rating: 600 V
Max. Operating Temperature: +150 °C
Min. Operating Temperature: -100 °C


NEMA WC 27500
SB SAE AS22759/32 XLETFE 150oC
SC SAE AS22759/33 XLETFE 200oC
SD SAE AS22759/34 XLETFE 150oC
SE SAE AS22759/35 XLETFE 200oC
SM SAE AS22759/41 XLETFE 200oC
SN SAE AS22759/42 XLETFE 200oC
SP SAE AS22759/43 XLETFE 200oC
SR SAE AS22759/44 XLETFE 200oC
SS SAE AS22759/45 XLETFE 200oC
ST SAE AS22759/46 XLETFE 200oC
