MIL-W-2275932 XLETFE CROSS LINKED ETFE (TEFZEL)WIRE
- Payment Type:
- T/T
- Incoterm:
- FOB
- Min. Order:
- 20000 Meter
- Min. Order:
- 20000 Meter
- Delivery Time:
- 10 Days
- Transportation:
- Land
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 3000km |
| Supply Ability: | 300km |
| Payment Type: | T/T |
| Incoterm: | FOB |
| Certificate: | UL |
| Transportation: | Land |
M22759/43-14-9 SPC WHT XL ETFE 600V 200C
Conductor Material: SILVER PLATED COPPER
Conductor Size: 14 AWG (AMERICAN WIRE GAUGE)
Conductor Stranding: 19 STRANDS IN EACH CONDUCTOR
Insulation Color: WHITE
Insulation Material: XLETFE-CROSS LINKED ETFE (TEFZEL)
Mil Spec: MIL-W-22759/43
Product Type: M22759
RoHS Compliant: NOT DECLARED
Shielded: NOT SHIELDED
Temperature Rating: 200 DEGREES CENTIGRADE (393 F)
Voltage Rating: 600 VOLTS AC OR DC
Description
ETFE copolymer
Stranded conductor
Applications
High-temperature airframe and avionics wire used in open harness applications.
Specifications
CONDUCTOR: Silver-plated Copper
INSULATION: ETFE (Tefzel), cross-linked extruded, modified, dual wall, irradiated
TEMPERATURE: 150C
VOLTAGE: 600 V
