Axial Thermal Cut-off with Rated Current of 3A and 82, ±2°C Fusing-off Temperature

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Rated functioning temperature (TF):

P0: 84°C
P1: 102°C
P2: 115°C
P3: 125°C
P4: 130°C
P5: 135°C
P9: 138°C
P7: 150°C
P12: 145°C

Fusing-off temperature:

P0: 82±2°C
P1: 98±2°C
P2: 112±3°C
P3: 120±3°C
P4: 126±2°C
P5: 131±3°C
P9: 135±2°C
P7: 145±3°C
P12: 140±2°C

Holding temperature (TH):

P0: 55°C
P1: 63°C
P2: 75°C
P3: 85°C
P4: 90°C
P5: 90°C
P9: 95°C
P7: 105°C
P12: 102°C

Maximum temperature limit (TM): 180°C

Rated current (Ir): 3A

Rated voltage (Ur): 250V AC

Safety approvals:

P0, P1, P2, P3, P4, P5, P9, P7: UL, CUL, VDE, PSE and CCC
P12: VDE and PSE

P0: 84°C

P1: 102°C

P2: 115°C

P3: 125°C

P4: 130°C

P5: 135°C

P9: 138°C

P7: 150°C

P12: 145°C

P0: 82±2°C

P1: 98±2°C

P2: 112±3°C

P3: 120±3°C

P4: 126±2°C

P5: 131±3°C

P9: 135±2°C

P7: 145±3°C

P12: 140±2°C

P0: 55°C

P1: 63°C

P2: 75°C

P3: 85°C

P4: 90°C

P5: 90°C

P9: 95°C

P7: 105°C

P12: 102°C

P0, P1, P2, P3, P4, P5, P9, P7: UL, CUL, VDE, PSE and CCC

P12: VDE and PSE
