LED Streetlights, Bridgelux LEDs and Meanwell Driver, IP65, HotSell, Dolphin Model

LED Streetlights, Bridgelux LEDs and Meanwell Driver, IP65, HotSell, Dolphin Model

Get Latest Price

Payment Type:: T/T, L/C, Western Union or PayPal

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union or PayPal

Product Description

Parameters:

Input voltage: AC 220V
Model no.: LX-SL950-150W
- Bridgelux LED quantity (multi-chip): 3x50W COB
- Input power range: 164W±1W
- Input voltages: AC 90-305V/DC 10-28V
- PF: >0.97
- Luminous flux range: 13,500-15,000lm
Model no.: LX-SL950-180W
- Bridgelux LED quantity (multi-chip): 3 x 60W COB
- Input power range: 196±1W
- Input voltages: AC 90-305V/DC 10-28V
- PF: >0.97
- Luminous flux range: 16,200-18,000lm
Model no.: LX-SL950-210W
- Bridgelux LED quantity (multi-chip): 3x70W COB
- Input power range: 230W±2W
- Input voltages: AC 90-305V/DC 10-28V
- PF: >0.97
- Luminous flux range: 18,900-21,000lm
LED working voltages: 30-36V
Related color temperatures (CCTs):
- Cool white: 6,000-7,000K
- Pure white: 4,500-5,500K
- Warm white: 3,000-4,000K/2,700-2,900K
Other available colors: red, yellow, blue and green amber
Color rendering index (CRI):
- CW/PW: ≥80Ra
- WW: ≥70Ra
Uniformity of illuminance: 0.7
Distribution of the light: LED+ optical glass lens
The curve of light distribution: asymmetric (bat wing)/rectangular beam
Working humidity range: -10-90% RH
Storage temperatures: -25-65°C
Material for light: aluminum
Case colors available: gray, black, silver, white
IP rating: IP65
Size for pole diameters: Ø50 or Ø60mm
Net weight: 11.3kg
Gross weight: 12.8kg
Package size: 1240*480*210mm/1pc

Simple description:

Product name: LED streetlight (30-80W)
Product no: LX-SL650 series (30-80W)
Input voltages: AC 85-265V, 277/305V, 47-63Hz DC 10-28V
Colors: CW, PW and WW
LED efficiency: >100lm/W
Working temperatures: -40-50°C
Lifespan for LED lighting source: >50,000 hours
Certifications: CE, RoHS, FCC, SGS and KEMA
Manufacturer: Shenzhen Lux lighting Co.,Ltd., LX-SL650, 30-80W LED streetlight

Features:

More than 70% energy saving
2014 newest design
Autonomy in package of LED light source Bridgelux/Epistar LED chip
Original American CREE LED or Philips LumiLEDs LED used
Universal input voltages: AC 85-265/277/305V/DC 10-28V
0-10V/PWM/DALI dimming function, saving further energy
High quality Taiwan Meanwell driver, reliable and stable
Automatically reduce current

Input voltage: AC 220V

Model no.: LX-SL950-150W

Bridgelux LED quantity (multi-chip): 3x50W COB
Input power range: 164W±1W
Input voltages: AC 90-305V/DC 10-28V
PF: >0.97
Luminous flux range: 13,500-15,000lm

Model no.: LX-SL950-180W

Bridgelux LED quantity (multi-chip): 3 x 60W COB
Input power range: 196±1W
Input voltages: AC 90-305V/DC 10-28V
PF: >0.97
Luminous flux range: 16,200-18,000lm

Model no.: LX-SL950-210W

Bridgelux LED quantity (multi-chip): 3x70W COB
Input power range: 230W±2W
Input voltages: AC 90-305V/DC 10-28V
PF: >0.97
Luminous flux range: 18,900-21,000lm

LED working voltages: 30-36V

Related color temperatures (CCTs):

Cool white: 6,000-7,000K
Pure white: 4,500-5,500K
Warm white: 3,000-4,000K/2,700-2,900K

Other available colors: red, yellow, blue and green amber

Color rendering index (CRI):

CW/PW: ≥80Ra
WW: ≥70Ra

Uniformity of illuminance: 0.7

Distribution of the light: LED+ optical glass lens

The curve of light distribution: asymmetric (bat wing)/rectangular beam

Working humidity range: -10-90% RH

Storage temperatures: -25-65°C

Material for light: aluminum

Case colors available: gray, black, silver, white

IP rating: IP65

Size for pole diameters: Ø50 or Ø60mm

Net weight: 11.3kg

Gross weight: 12.8kg

Package size: 1240*480*210mm/1pc

Bridgelux LED quantity (multi-chip): 3x50W COB

Input power range: 164W±1W

Input voltages: AC 90-305V/DC 10-28V

PF: >0.97

Luminous flux range: 13,500-15,000lm

Bridgelux LED quantity (multi-chip): 3 x 60W COB

Input power range: 196±1W

Input voltages: AC 90-305V/DC 10-28V

PF: >0.97

Luminous flux range: 16,200-18,000lm

Bridgelux LED quantity (multi-chip): 3x70W COB

Input power range: 230W±2W

Input voltages: AC 90-305V/DC 10-28V

PF: >0.97

Luminous flux range: 18,900-21,000lm

Cool white: 6,000-7,000K

Pure white: 4,500-5,500K

Warm white: 3,000-4,000K/2,700-2,900K

CW/PW: ≥80Ra

WW: ≥70Ra

Product name: LED streetlight (30-80W)

Product no: LX-SL650 series (30-80W)

Input voltages: AC 85-265V, 277/305V, 47-63Hz DC 10-28V

Colors: CW, PW and WW

LED efficiency: >100lm/W

Working temperatures: -40-50°C

Lifespan for LED lighting source: >50,000 hours

Certifications: CE, RoHS, FCC, SGS and KEMA

Manufacturer: Shenzhen Lux lighting Co.,Ltd., LX-SL650, 30-80W LED streetlight

More than 70% energy saving

2014 newest design

Autonomy in package of LED light source Bridgelux/Epistar LED chip

Original American CREE LED or Philips LumiLEDs LED used

Universal input voltages: AC 85-265/277/305V/DC 10-28V

0-10V/PWM/DALI dimming function, saving further energy

High quality Taiwan Meanwell driver, reliable and stable

Automatically reduce current
