LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
  • LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
  • LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
  • LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
  • LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
  • LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
  • LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
  • LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
  • LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency
LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency

LED Streetlight, 120W, Meanwell Driver, Cree LEDs, IP66, 47-63Hz Frequency

Get Latest Price
Payment Type:
T/T, L/C, Western Union or PayPal
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T, L/C, Western Union or PayPal
Product Description
Product Description
  • Main technology index:
    • Model no: LX-SL96
    • Equivalent: 250W high-pressure sodium lamp
    • LED light source: 96 x 1W Cree LED/Philips LumiLEDs
    • LED luminous efficiency: 107-122lm/W
    • Lamp total power: 120W
    • Power efficiency: 91%
    • Lamp rated luminous flux: >11,000lm
    • Lamp rated luminous efficiency: >95lm/W
    • Average illumination and effective area:
      • 8m height: 26x10m, ≥35 Lux
      • 10m height: 33x13m, ≥24 Lux
      • 12m height: 40x16m, ≥17 Lux
    • Color rendering index (CRI): >75Ra
    • Color temperature:
      • Cool white: 5,700K
      • Pure white: 4,500K
      • Warm white: 3,000K
    • Beam angle: 140 x 75°
    • Light distribution curve (beam pattern): asymmetric (bat wing)/rectangular beam
    • Input voltage: 85-265/277V AC, 10-28V DC
    • Frequency range: 47-63Hz
    • Power factor (PF): 0.96
    • Total harmonic distortion (THD): <15%
    • Storage temperature: -40-80°C
    • Working environment: -40-50°C, 10-95% RH
    • Junction temperature (Tj): 60°C ±10% (ta=25°C)
    • Light body and lampshade materials: aluminum alloy and ASA/PC
    • Working lifespan: >50,000 hours
    • IP rating: IP66
    • Net weight: 8.4kg
    • Gross weight: 9.5kg
    • Size: 671x315x204mm
    • Package size: 737x370x280mm (1 piece)
  • Features:
    • More than 70% energy-saving
    • 3x8 LED module design, convenient for maintenance
    • Original American Cree LED or Philips LumiLEDs LED used
    • Light control and time-phase dimming, saving further energy
    • High-quality power supply, reliable and stable
    • Automatically reduce current against overheating temperature
    • Unique optical design and rectangular beam, suitable for roadway illumination
  • Applications:
    • For main road, sidewalk, square, schools, parks, garden, factory, residential places, villa and many other projector lighting places
  • Based on the classic modular design-our first generation LED streetlight, our upgraded generation improves the module design as 3 x 8 arrays
  • Although LEDs were deducted, but the light efficiency is much higher and much more effective based on the dual lens design
  • Model no: LX-SL96
  • Equivalent: 250W high-pressure sodium lamp
  • LED light source: 96 x 1W Cree LED/Philips LumiLEDs
  • LED luminous efficiency: 107-122lm/W
  • Lamp total power: 120W
  • Power efficiency: 91%
  • Lamp rated luminous flux: >11,000lm
  • Lamp rated luminous efficiency: >95lm/W
  • Average illumination and effective area:
    • 8m height: 26x10m, ≥35 Lux
    • 10m height: 33x13m, ≥24 Lux
    • 12m height: 40x16m, ≥17 Lux
  • Color rendering index (CRI): >75Ra
  • Color temperature:
    • Cool white: 5,700K
    • Pure white: 4,500K
    • Warm white: 3,000K
  • Beam angle: 140 x 75°
  • Light distribution curve (beam pattern): asymmetric (bat wing)/rectangular beam
  • Input voltage: 85-265/277V AC, 10-28V DC
  • Frequency range: 47-63Hz
  • Power factor (PF): 0.96
  • Total harmonic distortion (THD): <15%
  • Storage temperature: -40-80°C
  • Working environment: -40-50°C, 10-95% RH
  • Junction temperature (Tj): 60°C ±10% (ta=25°C)
  • Light body and lampshade materials: aluminum alloy and ASA/PC
  • Working lifespan: >50,000 hours
  • IP rating: IP66
  • Net weight: 8.4kg
  • Gross weight: 9.5kg
  • Size: 671x315x204mm
  • Package size: 737x370x280mm (1 piece)
  • 8m height: 26x10m, ≥35 Lux
  • 10m height: 33x13m, ≥24 Lux
  • 12m height: 40x16m, ≥17 Lux
  • Cool white: 5,700K
  • Pure white: 4,500K
  • Warm white: 3,000K
  • More than 70% energy-saving
  • 3x8 LED module design, convenient for maintenance
  • Original American Cree LED or Philips LumiLEDs LED used
  • Light control and time-phase dimming, saving further energy
  • High-quality power supply, reliable and stable
  • Automatically reduce current against overheating temperature
  • Unique optical design and rectangular beam, suitable for roadway illumination
  • For main road, sidewalk, square, schools, parks, garden, factory, residential places, villa and many other projector lighting places
