420TVL Parking Lots Vehicle License Plate White Light Lamp Camera Series

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Features:

White light lamp irradiation by light source
With special white light automatic modulation function, it can also show the vehicle license plates figure very clearly when the car lights are either on or off
The housing is made by special material, thus being waterproof up to IP65 grade
Uses accurate constant current source technology, the LED board is designed separately from the control circuit board to make it more stable
High-power lighting protection circuit makes the CCD board more stable
The CCD board is designed by two PCB boards, every PCB board has four layers of circuit, to make it work while in a strengthened state
Image sensor: 1/3 color Sony CCD
Total pixels:
- PAL (H x V): 542 x 582
- NTSC (H x V): 542 x 582
Scanning system: PAL/NTSC
Sync system: internal
Illumination: 1 Lux F1.2/0 Lux (IR-on) (minimum)
Resolution: 420TVL
Lens: 1 Lux F 1.4/0 Lux MTV 4 to 16mm (optional)
IR distance range: 0 to 50m
WBC: 1/50 to 1/100,000 auto
AG: AGC
S/N ratio: ≥48dB
Exposure time: auto
Auto iris: electronic shutter
Mirror function: on/off optionally
BLC: on/off optionally
Video output: 1.0Vp-p/75Ω
Gamma correction: 0.45
Working temperature range: -20 to -50 degrees Celsius
Working humidity: 85% RH
Power supply: 12V DC
Power consumption: ≤300mA
Measurements: 112 x 65 x 60mm

White light lamp irradiation by light source

With special white light automatic modulation function, it can also show the vehicle license plates figure very clearly when the car lights are either on or off

The housing is made by special material, thus being waterproof up to IP65 grade

Uses accurate constant current source technology, the LED board is designed separately from the control circuit board to make it more stable

High-power lighting protection circuit makes the CCD board more stable

The CCD board is designed by two PCB boards, every PCB board has four layers of circuit, to make it work while in a strengthened state

Image sensor: 1/3 color Sony CCD

Total pixels:
