CVI Megapixel Camera, Measures 280 x 136.9 x 101mm

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Advance T/T or PayPal

Product Description

Features:

1/3CMOS, DH9801 sensor, 1,280 x 960 pixels
High-quality image
With HD CVI digital port, support coaxial video cable transmitting distance 500 meters
Real-time transmission, without delay
Support for high-definition video signal coaxial transmission
ICR switching support to achieve the day and night monitoring
Support 3D noise reduction and extra low illumination
Waterproof rate: IP66
Two camera colors optional

Specifications:

Lens: 2.8-12 lens
IR LED: 36 pieces of IR LED, 30m IR distance
Image sensor: 1/3 CMOS pixels, X-KHAN (PC3100K)
Main processor: ISP processor DH9801
Resolution (H x V): 1,280 x 960 pixels
Day and night auto (ICR)/color/B/W
Linux 0.01 Lux/F1.2 (color), 0.001 Lux/F1.2 (B/W)
WB auto
Video frame rate: 1,280*720, 25fps, 720x576, 50fps
Video output: 1-channel BNC HDCVI high-definition video output/CVBS standard definition video output (can switch)
Image adjustment can adjust image lightness, sharpness, contrast and more
Gamma adjustment support 16 pieces of gamma curve
3D DNR support
Power supply: 12V DC±10%
Power consumption: 7.7W (maximum)
Working environment: -30 to +60°C/less than 95% RH (non-condensation)
Ingress protection: IP66
Transmission: distance over 500m via 75-3 coaxial cable
Dimensions (W×D×H): 280x136.9x101mm
Weight: 0.5kg
