H.264 Standalone CCTV DVR with D1/960H Resolution, dvr cloud Supports Alarm, E-SATA and P2P Functio

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Functions:

High-performance CPU, HDMI/VGA/TV/spot out simultaneous video output
H.264 dual-stream video compression, full channel D1/960H real-time recording
Simultaneous 16CH D1 full real-time record, network-transmission, playback & 16CH CIF/QCIF sub-code stream
Zoom function in both preview, playback, supports varied PTZ control protocols, embedded Web visiting, HTTP/MTP/DDNS/DHCP/PPPOE & NAT traversing
Supports cloud network (P2P)
Built-in DDNS makes the network connection easy & simple
UPNP (universal plug and play) (no need to forward ports in the router)
Supports movable hard-disk backup

Parameters:

Main processor: dual core embedded processor
Operation system: embedded Linux
Controls: USB mouse/wireless mouse/IR remote/front panel & network
Image splits: 1/4/9/16
Video standards: PAL (625TVL, 50fps/second) , NTSC (525TVL, 60fps/second)
Video compression: H.264
Preview, playback quality:
- D1: PAL (720 x 576)/NTSC (720 x 480P)
Sync playback: 1 to 16CH D1 (real-time)
Video detection: motion
MD zones: 396 (22 x 18), video loss & camera blank
Audio compression: G711A
Intercom: supported
Record modes: manual/alarm/motion/timing
Record rate:
- PAL range: 1 to 25fps
- NTSC range: 1 to 30fps
Video search: time/date, alarm, motion detection, log, event & channel
Record storage: local HDD, network
Backup modes: network/flash disk/movable HDD/internal SATA burner
Video/audio input: 16 BNC/BRC
Video outputs: 1 HDMI/VGA/BNC/spot out
Audio output: 1 RCA
Alarm: 16CH input, 3CH output, trigger events: recording, PTZ/tour/alarm/video push/email/FTP/spot/buzzer/screen tips
Network: RJ45 10/100M self-adjusted Ethernet interface/remote surveillance/playback, configuration, PTZ control, backup, information search, supports IE & CMS
PTZ: 1RS 485, 2 x USB2.0
SATA: 4HDD (or 3HDD+ 1CD/DVD RW)
E-SATA/loop-out: supported
Mobile surveillance: iPhone/Google's Android/Symbian/Microsoft's Windows/RIM's BlackBerry
Power

High-performance CPU, HDMI/VGA/TV/spot out simultaneous video output

H.264 dual-stream video compression, full channel D1/960H real-time recording

Simultaneous 16CH D1 full real-time record, network-transmission, playback & 16CH CIF/QCIF sub-code stream

Zoom function in both preview, playback, supports varied PTZ control protocols, embedded Web visiting, HTTP/MTP/DDNS/DHCP/PPPOE & NAT traversing

Supports cloud network (P2P)

Built-in DDNS makes the network connection easy & simple

UPNP (universal plug and play) (no need to forward ports in the router)

Supports movable hard-disk backup

Main processor: dual core embedded processor

Operation system: embedded Linux

Controls: USB mouse/wireless mouse/IR remote/front panel & network

Image splits: 1/4/9/16

Video standards: PAL (625TVL, 50fps/second) , NTSC (525TVL, 60fps/second)

Video compression: H.264

Preview, playback quality:

D1: PAL (720 x 576)/NTSC (720 x 480P)

Sync playback: 1 to 16CH D1 (real-time)

Video detection: motion

MD zones: 396 (22 x 18), video loss & camera blank

Audio compression: G711A

Intercom: supported

Record modes: manual/alarm/motion/timing

Record rate:

PAL range: 1 to 25fps
NTSC range: 1 to 30fps

Video search: time/date, alarm, motion detection, log, event & channel

Record storage: local HDD, network

Backup modes: network/flash disk/movable HDD/internal SATA burner

Video/audio input: 16 BNC/BRC

Video outputs: 1 HDMI/VGA/BNC/spot out

Audio output: 1 RCA

Alarm: 16CH input, 3CH output, trigger events: recording, PTZ/tour/alarm/video push/email/FTP/spot/buzzer/screen tips

Network: RJ45 10/100M self-adjusted Ethernet interface/remote surveillance/playback, configuration, PTZ control, backup, information search, supports IE & CMS

PTZ: 1RS 485, 2 x USB2.0

SATA: 4HDD (or 3HDD+ 1CD/DVD RW)

E-SATA/loop-out: supported

Mobile surveillance: iPhone/Google's Android/Symbian/Microsoft's Windows/RIM's BlackBerry

Power

D1: PAL (720 x 576)/NTSC (720 x 480P)

PAL range: 1 to 25fps

NTSC range: 1 to 30fps
