Product Description
Product Description
  • Specifications:
    • Specification: 4P + F
    • Rated temperature: 60 or 75°C
    • Unshielded twisted pairs:
      • Conductor: 26 or 24AWG stranding or solid bare copper
      • Insulation: HD-PE
      • Filler: PE cross or FM-PE thin slice
    • Unrip rope: optional
    • Jacket: PVC or LSZH
    • Impedance: 100 ±15%Ω at 1-250MHz
    • Reference standards: YD/T1019-2001, ANSI/TIA/EIA-568B and UL 444
    • Print legend: CM or CMR
  • Features
    • Separator inside the cable realizes the more stable transmission
    • Solid copper conductor allows high-performance
    • Fast and reliable connection
    • Twisted pairs with bright color for easy recognition
    • Ripcord and footmark for convenient use
    • Smooth jacket for easy pulling in tight space
    • Color in light grey, dark grey, blue, white or as per your requirement
    • Cabling standards meet: 10BASE-T/100BASE-Tx/100BASE-T4/1000BASE-T
    • The effective bandwidth of data layer is 10GB/second, the maximum transmission distance is 100 meters
    • Cross isolation structure and the thicker jacket effectively avoid the crosstalk between each pair of the cable
    • Single shield structure, make the cable have strong anti-interference ability to the outside World and transmit the signal in confidence
  • Applications:
    • Computer network cabling projects
    • Broadband network communication
    • Digital ISDN network and ATM 155Mbps network
    • Ethernet network
    • Audio and data transmission
    • Packing: 305m/carton
    • UTP Cat6a cable, 100m passed DTX-1800 fluke test
  • Specification: 4P + F
  • Rated temperature: 60 or 75°C
  • Unshielded twisted pairs:
    • Conductor: 26 or 24AWG stranding or solid bare copper
    • Insulation: HD-PE
    • Filler: PE cross or FM-PE thin slice
  • Unrip rope: optional
  • Jacket: PVC or LSZH
  • Impedance: 100 ±15%Ω at 1-250MHz
  • Reference standards: YD/T1019-2001, ANSI/TIA/EIA-568B and UL 444
  • Print legend: CM or CMR
  • Conductor: 26 or 24AWG stranding or solid bare copper
  • Insulation: HD-PE
  • Filler: PE cross or FM-PE thin slice
  • Separator inside the cable realizes the more stable transmission
  • Solid copper conductor allows high-performance
  • Fast and reliable connection
  • Twisted pairs with bright color for easy recognition
  • Ripcord and footmark for convenient use
  • Smooth jacket for easy pulling in tight space
  • Color in light grey, dark grey, blue, white or as per your requirement
  • Cabling standards meet: 10BASE-T/100BASE-Tx/100BASE-T4/1000BASE-T
  • The effective bandwidth of data layer is 10GB/second, the maximum transmission distance is 100 meters
  • Cross isolation structure and the thicker jacket effectively avoid the crosstalk between each pair of the cable
  • Single shield structure, make the cable have strong anti-interference ability to the outside World and transmit the signal in confidence
  • Computer network cabling projects
  • Broadband network communication
  • Digital ISDN network and ATM 155Mbps network
  • Ethernet network
  • Audio and data transmission
  • Packing: 305m/carton
  • UTP Cat6a cable, 100m passed DTX-1800 fluke test
