Wired 1D Laser Barcode Scanner, Platform MN200, 70*50*22mm External Size

Wired 1D Laser Barcode Scanner, Platform MN200, 705022mm External Size

Get Latest Price

Payment Type:: Bank Transfer, Western Union, PayPal or Escrow

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Bank Transfer, Western Union, PayPal or Escrow

Product Description

Light source type: visual lasing diode, wave length 650mm

Trigger mode: automatic (note: this trigger mode is the technology which researched and developed independently by our company, compare the automatic induction technology used in the domestic and overseas barcode scanner field, it's more convenient and reasonable)

Scanning mode: single-line scanning

Scanning speed: 100 ±2 times/second

Resolution: ≥4-mil

Printing contrast ratio: the lowest reflectivity difference is 30％

Bit error rate: 1/50 million

Input voltage: 5V DC ±0.25V

Power: 325mW (work): 675mW (momentary maximum)

Current: 65mA (work): 135mA (momentary maximum)

Light intensity: 3,000-12,000 Lux

Depth of field: 5-630mm

Scanning angle: ±60, ±65, ±42° (left and right, front and back, rotation)

Decoding capacity：

UPC/EAN/JAN, UPC/EAN with supplemental, UCC/EAN 128, Code 39, MSI, Code11
Code 39 Full ASCII, Code 39 TriOptic, Code 128, Code 128Full ASCII
Codabar, Code93, Discrete2of5, IATA, RSSvariants, Codabar, Chinese2of5,
International general dimensional barcodes, e.g. Inteleaved2/5, Interleaved2of5, China postal service code and more

Prompt mode buzzer and LED indicator

Cable interface: USB (standard): Sony's PS/2 and RS232 are selectable.

External dimensions (L x W x H): 70*50*22mm

Weight: 58g (excluding cables)

Cable standard: straight line, 1m

Interface type: RJ-45 crystal head

Hull materials: ABS + PC

Temperature: 0 to 50℃ (work): -40 to 60℃ (storage)

Setting mode Automatic (scanning and setting barcodes according to the sequence)

UPC/EAN/JAN, UPC/EAN with supplemental, UCC/EAN 128, Code 39, MSI, Code11

Code 39 Full ASCII, Code 39 TriOptic, Code 128, Code 128Full ASCII

Codabar, Code93, Discrete2of5, IATA, RSSvariants, Codabar, Chinese2of5,
