High-voltage Rectangle 120V AC Electric Motor with Cage Brush System for Coffee Machine, Power Brush

High-voltage Rectangle 120V AC Electric Motor with Cage Brush System for Coffee Machine, Power Brush

Get Latest Price

Payment Type:: T/T, L/C, Western Union, Cash, PayPal or MoneyGram

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union, Cash, PayPal or MoneyGram

Product Description

Features:

DMD insulation
Cage brush system
Metal end cap
8/12 slots armature
16/24 bars commutator

Dimensions:

Diameter of the motor: 37.8mm
Length of the motor: 67mm
Diameter of the shaft: 3.175mm

Specifications:

Voltage:
- Operating range: AC rectangle
- Nominal voltage: 120V
No loading:
- Speed: 12,800rpm
- Current: 0.1A
At maximum efficiency:
- Speed: 11,118rpm
- Current: 0.66A
- Torque: 499.8g.cm
- Output: 57.05W
Stall torque: 3,805g.cm
Stall current: 4.32A
Direction of rotation: CW/CCW
Note: all of the data could be custom made

Typical applications:

Coffee machine
Power brush
Hand blender
Hair clipper

Customization options:

OEM and customization are available
With RoHS Directive-compliant
Ball bearing in output side
EMI suppression
Low-cogging design
High-degree of protection
Small mechanical time constant
Resist intense vibrations
Zero Axial gap
Low-noise design
Fast response (small TM)
High-torque at a low-speed
PTC protection
Pinole resin base commentator
Epoxy coating armature
Lightweight and long lifespan

Our main products are DC motor, gear motor and vibration motor, the parameters can be customized

DMD insulation

Cage brush system

Metal end cap

8/12 slots armature

16/24 bars commutator

Diameter of the motor: 37.8mm

Length of the motor: 67mm

Diameter of the shaft: 3.175mm

Voltage:

Operating range: AC rectangle
Nominal voltage: 120V

No loading:

Speed: 12,800rpm
Current: 0.1A

At maximum efficiency:

Speed: 11,118rpm
Current: 0.66A
Torque: 499.8g.cm
Output: 57.05W

Stall torque: 3,805g.cm

Stall current: 4.32A

Direction of rotation: CW/CCW

Note: all of the data could be custom made

Operating range: AC rectangle

Nominal voltage: 120V

Speed: 12,800rpm

Current: 0.1A

Speed: 11,118rpm

Current: 0.66A

Torque: 499.8g.cm

Output: 57.05W

Coffee machine

Power brush

Hand blender

Hair clipper

OEM and customization are available

With RoHS Directive-compliant

Ball bearing in output side

EMI suppression

Low-cogging design

High-degree of protection

Small mechanical time constant

Resist intense vibrations

Zero Axial gap

Low-noise design

Fast response (small TM)

High-torque at a low-speed

PTC protection

Pinole resin base commentator

Epoxy coating armature

Lightweight and long lifespan
