3.7V DC Electric Motor for Electric Shavers, with 0.84W Output Power

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C, Western Union, Cash, PayPal or MoneyGram

Product Description

Dimensions:

Specifications:

Features:

Our products are DC motor, gear motor and vibration motor, the parameters can be customized according to your requirements

Diameter of housing: 15.5mm

Width of housing: 12mm

Length of housing: 26.5mm

Diameter of shaft: 1.5mm

Length of shaft: could be customized

Nominal voltage: 3.7V

No loading:

At maximum efficiency:

Speed: 16,800rpm

Current: 0.37A

Speed: 16,300rpm

Current: 0.6A

Torque: 5gcm

Output power: 0.84W

Stall torque: 180gcm

Stall current: 7.45A

Direction of rotation: CW/CCW

Permanent magnet

Oil-impregnated bearing

Precious metal brush/carbon brush

Stainless steel shaft
